Product Description
GD10-P00-17DG-OXH-00 is an infrared point combustible gas detector of Teledyne Simtronics GD10P series. It adopts dual-wavelength dual-path solid-state infrared absorption principle for methane (0~100%LEL) and hydrocarbon gas concentration monitoring. The detector features 316L stainless steel explosion-proof housing, HART7 communication protocol and standard 4-20mA analog output. Continuous built-in self-diagnostics can detect lens contamination, light source failure and optical path malfunction. Heated optics prevent condensation. Certified by ATEX / IECEx for hazardous areas. It features long service life and low signal drift, serving as core field instrument and spare part for F&G fire & gas systems.
Data Sheet
| Item | Specification |
|---|---|
| Model | GD10-P00-17DG-OXH-00 |
| Brand | SIMTRONICS (Teledyne) |
| Series | GD10P Series Infrared Point Gas Detector |
| Detection Principle | Dual-wavelength, dual-path infrared absorption, solid-state IR source |
| Detected Gas | Methane, measuring range 0~100%LEL |
| T90 Response Time | ≤4 seconds |
| Accuracy | ±3%FS (0~50%LEL); ±5%FS (50~100%LEL) |
| Power Supply | 24VDC, operating range 18~32VDC |
| Power Consumption | Approx.3.5W |
| Signal Output | 4~20mA, HART7 protocol supported |
| Wiring | 3-core shielded cable, 0.5~1.5mm²; M20 Ex cable gland |
| Housing Material | 316L Stainless Steel |
| Protection Rating | IP66 / IP67, NEMA4X |
| Explosion Certification | ATEX, IECEx |
| Operating Temperature | -40℃ ~ +60℃ |
| Storage Temperature | -40℃ ~ +70℃ |
| Relative Humidity | 0~100%RH, non-condensing |
| Diagnostics | Continuous self-test; pre-alarm for dirty optics, light source & optical fault detection |
| Dimension (L × W × H) | 264 × 104 × 106 mm |
| Weight | Approx.2.9kg |
| Origin | Norway |
Product Application
It is used for fire & gas (F&G) safety systems on offshore oil & gas platforms, LNG terminals, refineries, chemical plants, gas compressor rooms and tank farms; on-line monitoring of methane and hydrocarbon gas leakage in hazardous areas; triggering ESD interlock and leakage alarm. Suitable for high-risk explosion-proof locations such as offshore platforms and refining facilities. Used for instrument matching of new projects and replacement of aged detectors.
Related Series Models
- GD10-PE0: Infrared gas detector with long sample pipe
- GD10-P00-17DG-OXH-01: CO₂ infrared detector version
- GD10-P00-17DG-OXH-02: Multi-hydrocarbon calibrated version
- GD10-P00-27DG: Version with relay output
