Product Description
WITTENSTEIN alpha LPK‑090‑MO2‑10‑111 is a German‑manufactured high‑precision right‑angle servo gearbox, two‑stage bevel‑planetary gearing with 90‑degree output for space‑saving machine layout. Low‑backlash compound bevel‑planetary transmission, solid output shaft. Clamping‑hub motor interface supports various servo motor brands. Factory filled for lifetime lubrication, maintenance‑free operation. Heavy‑duty output bearings withstand high tilting moment, radial and axial loads. Excellent positioning accuracy and dynamic performance for high‑cycle, high‑dynamic servo applications. IP64 protection class, compact and robust alloy housing. This model is manufacturer discontinued; available as surplus new, used‑tested and refurbished spare parts for legacy‑machine replacement.
Technical Specifications
| Item | Specification |
|---|---|
| Model | LPK‑090‑MO2‑10‑111 (LPK090MO210111) |
| Type | Right‑angle servo bevel‑planetary gearbox, 2‑stage |
| Frame Size | 090 |
| Gear Ratio | i=10 |
| Output | Solid output shaft |
| Backlash | ≤8 arcmin |
| Nominal Output Torque T2N | 110 Nm |
| Max Acceleration Torque T2B | 190 Nm |
| Emergency‑Stop Torque T2Not | 190 Nm |
| Max Input Speed | 4000 rpm |
| Full‑load Efficiency | ≥94 % |
| Lubrication | Lifetime grease lubricated, maintenance‑free |
| Protection Class | IP64 |
| Ambient Temperature | ‑15℃ ~ +40℃ |
| Weight | Approx. 6.25 kg |
| Mounting | Clamping‑hub motor mounting, any mounting orientation |
| Origin | Made in Germany |
| Status | Manufacturer Discontinued, surplus / used‑tested / refurbished only |
Industry Applications
- Machine Tools: Right‑angle feed axis, B/C rotary axis drive for CNC, grinders, machining centers; spare‑part replacement for legacy machines.
- Packaging & Printing: High‑speed synchronized positioning for packaging lines, die‑cutters, printing presses.
- Robotics & Automation: Robot joints, seventh‑axis, transfer mechanisms requiring compact 90‑degree power transmission.
- Laser Equipment: Motion‑axis drive for laser cutting and laser marking systems.
- Textile Machinery: Multi‑axis synchronization and tension‑control mechanisms.
- Material Handling: Servo rotary drive for stacker cranes and transfer platforms.
- General Industrial Automation: High‑dynamic low‑backlash transmission where right‑angle power turn‑around is required; spare‑parts service for older production lines.
