Yokogawa AAI143-H53/K4A00 Analog Input Module

Product Description

AAI143-H53/K4A00 is a 16-channel isolated analog input module of Yokogawa FIO series for CENTUM VP / CENTUM CS DCS system, supporting HART protocol. Suffix H means HART communication enabled; 5 stands for non-explosion-proof; 3 indicates ISA G3 anti-corrosion grade and operating temperature range -20~70℃. /K4A00 includes KS cable interface adapter ATK4A-00 for connecting AEA4D terminal board. Each channel is individually isolated to acquire 4-20mA field signals and read diagnostic data from HART smart transmitters. It features strong noise immunity for DCS applications in chemical, power and other industrial plants.

Specifications

• Part No.: AAI143-H53/K4A00
• Manufacturer: Yokogawa
• Series: AAI143 FIO Analog Input Module for CENTUM VP DCS
• Channels: 16 isolated analog input channels
• Input Signal: 4~20mA DC, supports 2-wire /4-wire transmitters
• Communication: HART protocol (all channels)
• Accuracy: ±16μA
• Data Refresh Time: 10ms
• Isolation Withstand Voltage: 1500V AC (input to system, 1 min)
• Transmitter Power Supply: 19.0~25.5V DC, 25mA current limit
• Thermal Drift: ±16μA per 10℃
• Operating Temperature: -20℃ ~ +70℃, ISA G3 corrosive gas resistant
• Power Consumption: 230mA @5V DC; 540mA @24V DC
• Option /K4A00: KS cable interface adapter ATK4A-00 for AEA4D terminal block
• Weight: approx. 0.3kg

Applications

1. Petrochemical DCS for pressure, level, flow 4-20mA + HART instrument signal acquisition
2. Power plant boiler & turbine process data monitoring
3. Process control for pharmaceutical, pulp & paper, water treatment plants
4. Remote configuration and fault diagnosis of HART smart field devices
5. Industrial sites with corrosive gas environment (ISA G3 class)

AAI143 Series Part Numbers

• AAI143-S50: Standard 16CH AI, no HART, basic temperature
• AAI143-H50: With HART, basic temperature grade
• AAI143-S53: No HART, ISA G3, wide temperature
• AAI143-H53: With HART, ISA G3 wide temp (base card of this model)
• AAI143-SE0: No HART, explosion-proof type
• AAI143-HE0: With HART, explosion-proof type
• AAI143-SE3: No HART, explosion-proof + G3 wide temp
• AAI143-HE3: With HART, explosion-proof + G3 wide temp
