Product Description
ADV569-P00 is a 64‑channel digital input module compatible with ST6 bus for Yokogawa CENTUM‑VP DCS system, standard basic type. It adopts group‑isolated common‑minus design for every 16 channels. It collects dry‑contact signals from field switches, valve feedbacks and relay contacts, transmits discrete status to DCS controller. Hot‑swap supported, installed in ANB10D / ANB10S node unit, wired via KS9 dedicated cable. Widely used for DCS I/O expansion and spare‑part replacement in process‑industry interlock & status acquisition。
Suffix explanation:‑P=Standard type; 00=Basic version.
Technical Parameters
| Item | Specification |
|---|---|
| Model | ADV569-P00 |
| Manufacturer | YOKOGAWA Electric |
| Product Type | Digital Input Module (DI) |
| Compatible System | CENTUM‑VP, ST6 bus, FIO node unit ANB10D / ANB10S |
| Channels | 64‑ch input, group‑isolated per 16‑ch, common minus side |
| Input Type | Dry‑contact contact input |
| Contact Judgment | ON ≤200Ω；OFF ≥100kΩ |
| Contact Rating | 5VDC, ≥20mA |
| Response Time | 8ms |
| Power Consumption | 800mA @5VDC |
| Wiring | KS9 dedicated cable |
| Mounting | Hot‑swap on FIO slot |
| Weight | Approx. 0.30kg |
| Operating Temperature | 0℃ ~ +60℃ |
| Humidity | 5‑95%RH, non‑condensing |
Product Application
- Field discrete‑signal acquisition: Collect valve feedback, limit switch, relay, pump on‑off status for chemical, petrochemical and power plants.
- Interlock logic input: Receive field device status for DCS safety interlock and sequence control.
- DCS I/O expansion: Add massive DI points for CENTUM‑VP projects on ESB‑bus node units.
- Maintenance & spare‑part replacement: On‑site hot‑swap replacement for faulty modules to minimize plant downtime.
- Legacy DCS retrofitting: Discrete‑signal acquisition card for existing plant control‑system refurbishment.
Related Series Part Numbers
- ADV169‑PK0 64‑ch DI with KS0 cable interface
- ADV569‑P00 64‑channel digital output DO module
- ADV151‑P00 32‑channel digital input module
- ADV869‑P00 32DI+32DO mixed digital I/O module
- ADV161‑P50 32‑channel isolated DI module
