I. Model Explanation
ALE111: Third-party Ethernet communication card specifically for FIO rack
S00: Standard general-purpose, non-explosion-proof basic version
Basic Positioning
CENTUM VP DCS Field Control Station (FCS) expansion communication card, inserted into ANB10D/ANB11 etc. FIO backplane, to achieve Ethernet connection between DCS and third-party PLC, instrument, and upper-level system, with protocol conversion gateway function Yokogawa E… 。
Hardware Electrical Specifications
Network Port Parameters
Interface: Single-channel RJ45, IEEE802.3 10BASE-T (10Mbps half-duplex)
Cable: 100Ω unshielded twisted pair, maximum single segment length of 100m
Media Access: CSMA/CD, point-to-point / star networking
Power Consumption
Power drawn from backplane, working current 0.5A
Overall Machine Weight 0.3kg, Dimensions 163×38×58mm
Installation Compatible with Backplane
ANB10□, ANB11□, ANR10, AFV30D, AFF50 full series FIO expansion backplane (The previously queried ANB10D-445 can be directly plugged into the slot) Environment
Standard industrial temperature range: 0℃ to +50℃, cabinet free of condensation
Support for communication protocols (for connecting third-party devices)
The module is equipped with multiple protocol drivers. After FCS configuration, it can directly read and write external devices:
Modbus TCP (master / slave)
Mitsubishi MELSEC, Yokogawa FA-M3 PLC
Rockwell PLC-5/SLC500
DARWIN/DAQSTATION paperless recorder, YFGW gateway
Function: Share the main control communication load of FCS, without affecting the stable operation of the control cycle.
Core functions
Cross-vendor data interaction: DCS reads PLC, flow meters, analyzers, third-party vibration monitoring equipment (such as Bently 3500, EPRO, etc.)
Data isolation: Physical isolation between the external industrial control network and the internal ESB bus of DCS, enhancing system security
Communication fault diagnosis: Real-time reporting of network cable disconnection and equipment disconnection to the DCS alarm screen
Support for hot swapping: Module replacement without downtime, ESB bus communication not interrupted
Suffix version distinction Table
Model suffix Version difference
ALE111-S00 Standard indoor universal type (common model)
ALE111-S51 Explosion-proof safe area dedicated
ALE111-S00-S1 Dual network port redundant version
Accessories and Application Scenarios
Matching system: CENTUM VP R5/R6, ProSafe-RS safety system
Typical industries: Petrochemical refining, thermal power, water treatment, fine chemical DCS remote I/O expansion rack
Typical combination: ANB10D-445/CU2T/NDEL backplane + ALE111-S00, connect to the third-party auxiliary control system in the factory area
