Product Description
ABB 1MRK00008-KB is the dedicated HMI display and operation panel for Relion 670 series protection IEDs. It adopts a pluggable structure and can be mounted on the front of REL670, RET670, REB670 and other 670 series protection devices. Equipped with LCD screen, function keys and status LED indicators, it supports local viewing of measured values, alarm messages, fault records and protection settings. It also enables local switching operations and protection function control. This local operating unit matches the System 800xA substation automation system and is manufactured in Sweden.
Specifications
- Part No.: 1MRK00008-KB
- Brand: ABB
- Series: Relion 670
- Type: HMI Display & Operation Panel
- Compatible IEDs: REL670, RET670, REB670 and other 670 series protection relays
- Mounting: Front plug-in embedded installation
- Supporting software: PCM600
- Indicators: Run, Alarm, Trip LED lights
- Origin: Sweden
- Weight: Approx. 2kg
Application
It is widely used in medium and high voltage substation protection systems, including line protection, transformer protection and busbar protection. It is used for on-site inspection, setting verification, fault data retrieval, protection function switching and local control. Cooperating with substation automation systems for on-site maintenance, it is commonly supplied as replacement spare parts.
Similar Part Numbers
1MRK00008-KB 1MRK00008-MB 1MRK00008-MBr02 1MRK00008-LB
