ABB 2TLA020070R1800 Programmable Safety Controller

Product Description

ABB 2TLA020070R1800 (Pluto S46 v2) is a programmable safety controller (Safety PLC) of ABB Jokab Safety Pluto series, a high-end modular safety logic unit. It is equipped with 24 safety inputs and 16 safety outputs, supporting DYNlink safety bus. It can directly connect emergency stop buttons, safety gates, safety light curtains, safety mats and other safety sensors. It meets EN ISO13849-1 Category4 / PL e and IEC61508 SIL3 safety level, adopting fail-safe hardware architecture. Programmed by free Pluto Manager software, multiple Pluto units can be networked together. Widely used for safety circuit control in automated production lines and robot cells, it is a common spare part for safety systems of imported machinery.

Specifications

1. Model: 2TLA020070R1800 (Pluto S46 v2)
2. Product Type: Programmable Safety Controller / Safety PLC
3. Safety Inputs: 24 channels
4. Safety Outputs: 16 channels
5. Safety Level: EN ISO13849-1 Category4 / PL e; IEC61508 SIL3
6. Communication: DYNlink safety bus; supports PROFIsafe, CIP Safety, EtherCAT Safety
7. Programming Software: Pluto Manager (free license, ladder diagram / function block programming)
8. Power Supply: 24 VDC
9. Indication: 7-segment display for fault code
10. Mounting: DIN rail mounting
11. Protection Class: IP20 (mounted inside cabinet)
12. Operating Temperature: 0 ~ +55℃
13. Storage Temperature: -20 ~ +70℃
14. Humidity: 10~95%RH, non-condensing
15. Certifications: TÜV, CE, UL
16. Network: Up to 32 Pluto controllers on one safety bus

Applications

• Robotics: Robot cell safety protection, safety gate interlock, emergency stop, area guarding monitoring
• Automation Lines: Safety logic control for assembly, packaging and conveying machinery
• Machine Tools: Safety circuits for machining centers and stamping machines, monitoring of light curtains and safety mats
• PV & Lithium Industry: Dual-channel safety interlock protection for automatic workstations
• Retrofit Projects: Spare parts replacement and safety function upgrade for legacy imported machines
• Logistics: Safety monitoring and safe stop control for AS/RS and sorting systems

Family Models

2TLA020070R1700 Pluto S16 v2 2TLA020070R1500 Pluto B46 v2 2TLA020070R1600 Pluto B16 v2 2TLA020070R1400 Pluto R46 v2 2TLA020070R1300 Pluto R16 v2 2TLA020070R1900 Pluto S62 v2
