ABB 3BHB017688R0001 Power Module

Product Description

ABB 3BHB017688R0001, internal designation IPS21‑35AD, is an IPS21‑series Isolated Power Supply module dedicated for ABB medium‑voltage IGCT converters, compatible with ACS6000 and ACS5000 medium‑voltage drives. This unit provides galvanically‑isolated regulated power for IGCT gate‑driver circuits. High‑voltage isolation between input and output suppresses common‑mode interference and ensures safe, reliable operation of power‑semiconductor drive loops. Designed as a slot‑mount card inside converter cabinets, it serves as OEM spare part for drive‑system maintenance, retrofit and direct replacement for IGCT power‑unit assemblies.

Technical Specifications

1. Order Code: 3BHB017688R0001; Internal Model: IPS21‑35AD
2. Type: IGCT Isolated Gate‑Drive Power‑Supply Module
3. Input Voltage: 85‑264 VAC wide‑range AC input
4. Output: Isolated regulated output, rated power 35 W
5. Isolation: High‑voltage galvanic isolation between input and output
6. Protections: Built‑in over‑current, over‑voltage and short‑circuit protection
7. Operating Temperature:‑25 ℃ ~ +70 ℃; Storage Temperature‑40 ℃ ~ +85 ℃
8. Protection Class: IP20, cabinet‑internal card‑mount installation
9. Mechanical: Plug‑in card form factor for converter chassis slot mounting
10. Compatible Equipment: IGCT power units of ACS5000, ACS6000 medium‑voltage converters

Product Applications

1. Gate‑drive power supply for IGCT power units within ABB ACS5000 / ACS6000 medium‑voltage variable‑frequency drives
2. Spare‑part replacement for high‑power motor drive systems in metallurgy and mining
3. Maintenance & retrofitting for large variable‑speed drives in oil‑gas and chemical plants
4. Spare‑component renewal for power‑plant auxiliary medium‑voltage drive equipment
5. Service projects for large‑size industrial fans and pump medium‑voltage drives
6. Hardware upgrade & retrofit of legacy IGCT converter systems

Peer Series Part Numbers

1. 3BHB017687R0001 IPS21‑25AD
2. 3BHB017689R0001 IPS21‑50AD
3. 3BHB017690R0001 IPS21‑75AD
4. 3BHB017691R0001 IPS21‑100AD
5. 3BHB017686R0001 IPS21‑15AD
