ABB 3BHL000359P0001 High Voltage Frequency Conversion Drive Module

Product Description

Model: 3BHL000359P0001, ABB medium voltage drive power module, belongs to ACS6000 medium voltage inverter series power cell assembly. It adopts rack plug-in structure, integrating IGBT power devices, drive circuits, status monitoring and hardware protection circuits. Designed for medium-voltage high-power drive systems, it supports multi-cell series topology with comprehensive fault diagnosis. The power cell can be replaced online, suitable for high-power motor speed regulation to ensure stable operation of medium voltage drive systems.

Technical Specifications

• Model: 3BHL000359P0001
• Brand: ABB
• Type: Medium Voltage Inverter Power Cell
• Compatible System: ABB ACS6000 Medium Voltage Drive System
• Main Power Device: IGBT
• Cooling Method: Air Cooling
• Protection Class: IP20 (cabinet installation)
• Operating Temperature: 0℃ ~ +55℃
• Protection: Overcurrent, overvoltage, undervoltage, overtemperature, drive fault, short-circuit protection
• Mounting: Rack plug-in, online cell replacement supported
• Communication: Fiber optic communication between cell and main control board for status and control signals
• Features: Fiber isolated drive, cell status LED, built-in fault log, modular construction

Application

Used for high-power medium-voltage motor speed control:

1. Main drives for rolling mills, fans and water pumps in metallurgy
2. Boiler induced draft fans, forced draft fans and circulating water pumps in power plants
3. Large compressors and pump loads in petrochemical industry
4. Main ventilation fans and hoist high-power drives in mining
5. Large kiln main motors and raw material mill drives in cement industry Function: As the core power output cell of ACS6000 inverter, it realizes electric energy conversion and drives medium-voltage high-power motors for smooth speed regulation and energy-saving control. Modular design simplifies maintenance and reduces downtime.

Related Series Models

3BHL000359P0001 3BHL000359P0002 3BHL000359P0003 3BHL000359P0004 3BHL000359P0005
