ABB 64610805 RTAC-01 ACS800 frequency converter is equipped with a pulse encoder interface module.

Product Description

RTAC-01 (Part No.: 64610805) is a pulse encoder interface module for ABB ACS800 inverters, serving as the speed feedback acquisition unit of the drive system. The module receives pulse signals from incremental encoders, performs signal isolation, shaping and conversion, and feeds motor speed and position data back to the inverter main control board to realize high-precision vector control and closed-loop speed regulation. It is equipped with signal loss detection and fault diagnosis functions and features strong anti-interference performance. It is widely used for encoder signal acquisition in ACS800 single-drive / multi-drive systems, acting as a critical spare part for closed-loop speed regulation applications.

Specifications

• Model: RTAC-01
• ABB Part Number: 64610805
• Type: Pulse Encoder Interface Module
• Compatible Series: ABB ACS800 single-drive and multi-drive inverters
• Encoder Type: Incremental encoder (differential A/B/Z phases)
• Input Frequency Range: 0 … 300 kHz
• Power Supply: Powered internally by inverter
• Net Weight: 0.28 kg
• Operating Temperature: -20℃ ~ +60℃
• Storage Temperature: -40℃ ~ +85℃
• Protection Class: IP20 (when installed inside cabinet)
• Functions: Encoder pulse signal acquisition, signal isolation & shaping, speed and position feedback, wire break and fault diagnosis
• Certifications: CE, compliant with industrial drive standards

Applications

1. Closed-loop vector control of ABB ACS800 inverters, incremental encoder signal acquisition.
2. High-precision motor speed and position control in metallurgy, paper-making and textile industries.
3. Drive systems requiring accurate speed feedback such as mine hoists and cranes.
4. Closed-loop speed regulation retrofit and spare parts replacement for high-power motors in power plant and chemical process lines.
5. High-precision speed control for extruders, large fans and pumps.

Series Models

RTAC-01, RTAC-02, RTAC-03
