ABB ACS510-01-180A-4 Three-phase low-voltage AC inverter

Product Description

ACS510-01-180A-4 is a 3-phase low-voltage AC drive of ABB ACS510 series, rated power 90 kW and rated output current 180 A. It is optimized for fan and pump quadratic-torque loads with V/F scalar control. Standard built-in RFI filter, supporting functions such as cycling soft start, multi-pump sequence control and PID constant pressure regulation. Optional control panel and fieldbus adapters (Modbus, Profibus etc.) are available. Widely used in HVAC, water supply, wastewater treatment, tunnel ventilation and other energy-saving speed regulation applications. This series is gradually phased out and commonly supplied as spare parts for existing installations.

Technical Specifications

• Model: ACS510-01-180A-4
• Rated power: 90 kW
• Rated output current: 180 A
• Input supply: 3-phase 380~480 V AC, +10% / -15%, 48~63 Hz
• Control method: V/F scalar control, custom U/F curve supported
• Output frequency range: 0~500 Hz
• Overload capacity: 1.1×In for 1 minute every 10 minutes
• Switching frequency: default 4 kHz, selectable 1/4/8/12 kHz
• Power factor: ≈0.98
• Efficiency: approx. 98%
• Protection class: IP21 (standard)
• Ambient temperature: 0℃ ~ +40℃; derating required from 40℃ to 50℃
• Communication options: Modbus RTU, Profibus-DP and other fieldbus adapters
• I/O: Built-in analog and digital terminals, PID closed-loop ready
• Built-in components: Standard RFI filter; R6 frame with built-in AC reactor
• Certifications: CE, UL, cUL
• Mounting: Wall-mounted

Application

1. Energy-saving speed control for constant-pressure water pumps, circulating pumps and sewage pumps
2. Driving HVAC, cooling fans, tunnel and metro ventilation fans
3. Variable speed control for process fans and pumps in water treatment and chemical plants
4. Multi-pump duty/standby control for buildings, parks and auxiliary power plant systems
5. Spare replacement and energy retrofit for legacy ACS510 systems

Series Models

ACS510-01-125A-4, ACS510-01-157A-4, ACS510-01-195A-4, ACS510-01-246A-4, ACS510-01-290A-4
