ABB ACS880-07-0725A-3 Cabinet-type Single-Drive Frequency Converter

ABB ACS880-07-0725A-3 Cabinet-type Single-Drive Frequency Converter
I. Model Explanation
ACS880: ABB all-in-one industrial inverter series
07: Cabinet-type single-drive complete machine (factory-integrated in a standard control cabinet)
0725A: Rated output current 725A
3: Three-phase input voltage 380 – 415V (400V level)
Material code: 3AUA0000138146

Core Electrical Parameters Table
Parameter item Specification
Input specification Three-phase AC 380～415V, 50/60Hz
Rated output current 725A (light load rated); Heavy load current 566A
Applicable motor power Heavy load: 355kW; Light load: 400kW
Overload capacity 150% rated current can be sustained for 1 minute, 110% continuous operation
Control method DTC direct torque control, supports open-loop/ closed-loop control for asynchronous and synchronous motors
Protection level Standard IP22, optional IP42/IP54
Overall efficiency Approximately 98%

Product features
Integrated cabinet-type complete machine, with built-in rectification, inversion, fuse, main switch, convenient wiring, simple on-site installation and commissioning;
Standardized rich I/O interfaces, multiple bus communication (Profibus, Modbus, EtherNet/IP, etc.), compatible with DCS, PLC system networking;
Built-in safety torque shutdown (STO) safety function, meeting SIS, ESD safety system specifications;
Supports various optional components such as energy consumption braking, du/dt filter, EMC filter, etc., suitable for heavy-load working conditions such as fans, pumps, compressors, belt conveyors, hoists, etc.

Typical applications
High-power motor speed regulation in power, metallurgy, chemical industry, cement, mining, water treatment, oil and gas industries: boiler induced draft fans, circulating water pumps, air compressors, belt conveyor equipment, hoist lifting equipment, etc.
