ABB CB802 3BSE069285R1 Communication Expansion Module

ABB CB802 (Part Number: 3BSE069285R1)
I. Basic Positioning
CB802 = PROFIBUS DP Slave Communication Expansion Module
Compatible with Panel 800 V6 series human-machine touch screens, serving as an expansion for DP bus communication ports for human-machine interfaces, enabling the touchscreen to connect to the Profibus DP field bus network.
⚠️ Incompatible models: PP880R, PP885H, PP885M, PP885R, etc. of older screens from ABB.
II. Core Electrical Communication Parameters
Bus Protocol: PROFIBUS DP Slave (From Station)
Maximum Baud Rate: 12 Mbit/s (12000 kbit/s) from ABB
Installation Method: Plug-in expansion card, directly inserted into the internal expansion slot of Panel 800 V6 touch screen
Protection Certification: CE Certification, compliant with RoHS 2011/65/EU, WEEE 2012/19/EU environmental standards from ABB

Environmental and Physical Dimensions
Environmental Temperature and Humidity
Operating Temperature: -30℃ ~ +70℃
Storage Temperature: -40℃ ~ +80℃
Relative Humidity: 5%~95%, no condensation from ABB
Form and Weight
Height: 35 mm
Width: 130 mm
Net Weight: 0.18 kg from ABB

Accessories and Application Scenarios
Typical Matching Screens: PP865, PP875, PP886, etc. of Panel 800 V6 series touch screens Purpose:
The touchscreen acts as a DP slave station and exchanges data with AC800M, S800 I/O, and third-party DP controllers.
Expansion of HMI for Profibus-based automation systems in factories such as production lines, water treatment, metallurgy, and power.
Alternative / Same series: CB820 (another bus interface card, part number 7PAA002012R1)
