Product Description
DCS880-S02-0680-05X0 is a thyristor DC drive module of ABB DCS880‑S series, rack‑mount IP00 bare‑unit with rated armature DC output current 180 A for three‑phase mains supply. STO Safe Torque‑Off is integrated as standard with SIL3 / PL‑e certification. IEC 61131‑3 programming is supported for closed‑loop speed, torque and current control of DC motors. X0 configuration means no built‑in field exciter, external excitation unit is required. On‑board DDCS and Ethernet interfaces; Profinet, Modbus‑RTU, DP fieldbus modules are available as options. Commissioning via Drive Composer and Automation Builder software. Suitable for DC‑motor drives as well as non‑motor DC loads such as electrolysis and battery charging. Widely applied for new machinery and retrofit projects for legacy DCS400 / DCS500 systemsABB Group.
Technical Parameters
| Item | Specifications |
|---|---|
| Product family | DCS880‑S |
| Model | DCS880-S02-0680-05X0 |
| Quadrant operation | 2‑quadrant, single‑bridge, non‑reversing, non‑regenerative |
| Rated armature DC output current | 180 A DC |
| 3‑phase mains input | 100‑525 VAC; short‑term‑15%, continuous‑10%~+10% |
| Mains frequency | 50 Hz / 60 Hz |
| Max. armature output voltage | 0‑500 VDC |
| Module size | H3 |
| Suffix config | X0: standard terminals, 1st generation hardware, no built‑in exciter |
| Protection class | IP00 (cabinet installation) |
| Weight | 25 kg |
| Dimensions(H×W×D) | 460×270×317 mm |
| Safety functions | STO Safe Torque‑Off, SIL3 / PL‑e; over‑current, over‑voltage, under‑voltage, thermal, phase‑loss protection |
| Programming standard | IEC 61131‑3 |
| Commissioning software | Drive Composer Entry / Pro, Automation Builder |
| Communication | Ethernet, DDCS; optional DP, Modbus‑RTU, Profinet modules |
| Field excitation | External exciter unit required |
| Operating temperature | 0‑40 ℃ full load; derating mandatory from 40‑55 ℃ |
| Storage temperature | ‑25 ℃~+70 ℃ |
| Certifications | CE, UL |
Product Application
- Paper industry: rewinders, calenders, paper reel winding & unwinding drives
- Metal processing: auxiliary mill stands, wire‑drawing, winding & extrusion DC motor drives
- Crane & hoist: winch and slewing mechanism speed regulation
- Printing machinery: web‑press winding and unwinding
- Rubber & plastic: mixing machine, extruder auxiliary drives
- Non‑motor loads: electrolysis power supply, battery charging, magnet coil feeding
- Retrofit & spare‑part replacement for legacy DCS400 / DCS500 systems
2‑quadrant S01 series models (05 voltage range, X0 version)
DCS880‑S01‑0020‑05X0 DCS880‑S01‑0045‑05X0 DCS880‑S01‑0065‑05X0 DCS880‑S01‑0090‑05X0 DCS880‑S01‑0135‑05X0 DCS880‑S01‑0180‑05X0 DCS880‑S01‑0260‑05X0 DCS880‑S01‑0350‑05X0 DCS880‑S01‑0420‑05X0 DCS880‑S01‑0680‑05X0
