ABB DS2012SF60 3BHB023302R0001 Product Description
Model: 3BHB023302R0001
Brand: ABB
Category: High-power IGCT power semiconductor module (integrated gate commutation thyristor), some merchants also label it as rectifier diode power unit, frequency converter power module
Weight: Approximately 760g
Origin: Sweden
General Warranty Standard: New original 12 months
Core Electrical Specifications
Power Supply Compatibility: Power supply circuit for 120V AC side power supply components
Channels Output: 8 power output circuits
Fieldbus: Native support for Profibus communication
Operating Temperature: -20℃ ~ +70℃
Core Features: IGCT combines the high current withstand capability of GTO and the easy drive of IGBT, as well as low loss advantages. It also has built-in real-time fault diagnosis protection
Compatible Equipment and Application Scenarios
Matching Equipment
ABB medium and high voltage frequency converters, high-power converters, DCS800 DC speed control system
High-power power transmission units, soft starters, high-voltage rectifier bridge modules
Railway traction converters, high-power UPS, industrial power supplies, wind power converters
Industry Applications
Metallurgical rolling mills, mine hoists, large water pumps and fans transmission
Railway transportation, new energy power generation, ship power propulsion
Chemical, paper large power frequency drive systems
Product Features
High withstand voltage, large current carrying capacity, suitable for high-power power conversion scenarios
Low switching loss, strong stability for long-term continuous operation
Integrated self-check diagnosis, quickly locates overcurrent, overheating, short-circuit faults
Compact modular structure, saves space for cabinet installation
Wide temperature range industrial-grade design, suitable for dusty, temperature difference harsh environments
