ABB DSMB-01C ACS800 Multi-Drive Rectifier Unit Power Supply and Monitoring Board

Product Description

DSMB-01C is the power and monitoring board for ABB ACS800 multi-drive rectifier unit, a core component of ACS800 high-power drive system. This board supplies stable auxiliary power for the control circuit inside the rectifier unit, and monitors voltage, current and temperature signals of rectifier modules in real time. It implements fault detection and alarm output, with overvoltage, overcurrent and overheat protection functions. Adopted industrial-grade PCB design with strong EMC anti-interference performance. It is widely used for assembly of multi-drive cabinets and on-site spare parts replacement, serving as critical spare part for ACS800 rectifier unit.

Specifications

• Model: DSMB-01C
• Part Number: 64691929 / 64648896
• Type: Power & Monitoring Board
• Compatible Series: Rectifier unit of ABB ACS800 multi-drive inverter
• Net Weight: 0.95 kg
• Operating Temperature: -20℃ ~ +60℃
• Storage Temperature: -40℃ ~ +85℃
• Protection Class: IP20 (when installed inside drive cabinet)
• Functions: Auxiliary power supply, rectifier module status monitoring, fault acquisition, protection signal output
• Certifications: CE, compliant with industrial drive standards

Applications

1. Matching power and monitoring board for rectifier unit of ABB ACS800 multi-drive system.
2. Multi-motor drive cabinets for large production lines in metallurgy, paper making and mining industries.
3. Maintenance and spare parts replacement for high-power variable frequency drive systems in power plants and chemical industries.
4. Multi-drive units for heavy equipment such as large fans, pumps and extruders.
5. Retrofit and faulty board replacement of legacy ACS800 drive systems.

Series Models

DSMB-01C, DSMB-02C, DSMB-03C
