Product Description
NSD570 (ABB, Hitachi‑Energy, part number 1KHW000600R0001) is a modular teleprotection system for high‑voltage transmission networks. It transmits protection commands (trip, block, permissive) between substations over analog, E1/T1 digital, fiber‑optic and Ethernet‑IP links. It supports both hard‑wired contact interfaces and IEC 61850‑GOOSE for digital‑substation integration. Up to 4 analog commands and 8 digital/Ethernet commands are available; each command can be independently set for direct‑trip, permissive or blocking mode. Comprehensive self‑supervision and link monitoring are built‑in. Configuration is performed via browser‑based HMI570 tool over USB / RS‑232. Single or redundant power‑supply options are supported, compliant with IEC 60834‑1. OEM end‑of‑life, supplied as legacy maintenance spare for power‑utility sites.
Technical Parameters
| Item | Specification |
|---|---|
| Model | NSD570, part‑no.1KHW000600R0001 |
| Manufacturer | ABB (Hitachi Energy) |
| Product Type | Teleprotection signalling unit for power‑system line protection |
| Mounting | 19‑inch rack, 3U form‑factor |
| Command capacity | Max 4 analog commands; Max 8 digital / Ethernet commands |
| Command modes | Direct‑trip, permissive, blocking, per‑command configurable |
| Media support | Analog power‑line carrier, E1/T1, fiber‑optic, Ethernet‑IP |
| Protocols | IEC 61850 GOOSE, relay contact‑based interfaces |
| Configuration | Web‑based HMI570, USB, RS‑232 service port |
| Processor | 32‑bit RISC; 128 MB RAM / 256 MB Flash, embedded Linux |
| Power supply | 24‑250 VDC / 100‑240 VAC, dual‑redundant power supported |
| Ingress protection | IP20 (indoor cabinet installation) |
| Operating temperature | ‑25℃ ~ +55℃; storage‑40℃ ~ +70℃ |
| Humidity | 5‑95 %RH non‑condensing |
| Weight | Approx.1.5 kg |
| Certifications | CE, IEC 60834‑1 teleprotection standard |
| Status | OEM EOL discontinued, legacy utility spare part |
Product Application
- HV‑line pilot‑protection schemes: Transfer trip / block / permissive signals for POTT and DCB transmission‑line protection across substations.
- Legacy‑substation retrofitting: Drop‑in replacement for older teleprotection equipment, reuse existing carrier / E1 communication links.
- Digital‑substation deployment: GOOSE‑based teleprotection over IP‑networks for modern smart‑grid installations.
- Redundant protection link setup: Dual‑power and dual‑channel configurations for high‑reliability grid‑protection signalling.
- Utility‑site spare‑part replacement: On‑site unit swap to minimize transmission‑line protection outage duration.
Related Series Parts
- G1LA Analog line interface board for NSD570
- G1LB Digital E1/T1 line interface board
- G3LC Ethernet communication board
- P7LC Local display & operator panel
- NSD550 Previous‑generation teleprotection unit
