ABB P8461 Digital Output Module

Product Description

P8461 is a 32-channel digital output module of S800 I/O series for ABB System 800xA DCS system, which is the matching I/O unit for AC800M control system. The module provides 32 channels of 24V DC transistor digital outputs, divided into 4 isolated groups with short-circuit and overload protection for each group. It adopts module-level galvanic isolation and built-in status LEDs to feedback channel output and fault status in real time. It supports standard DIN rail mounting and communicates with the controller via I/O bus. It outputs digital on/off signals to drive field actuators such as relays, solenoid valves and indicator lights, serving as a common spare part for process industry DCS control systems.

Specifications

Model: P8461
Type: 32-Channel Digital Output Module (DO Module)
Compatible System: ABB System 800xA / AC800M Controller, S800 I/O Station
Number of Channels: 32 digital outputs, divided into 4 isolated groups
Output Type: 24V DC transistor output
Rated Current per Channel: 0.5A
Max Current per Group: 4A
Isolation: Module-level galvanic isolation
Protection: Short-circuit protection, overload protection
Indication: 32 channel status LEDs, power LED, 4 group fault LEDs
Mounting: DIN rail mounting
Net Weight: 0.38 kg
Operating Temperature: -20℃ ~ +60℃
Storage Temperature: -40℃ ~ +85℃
Protection Class: IP20 (installed inside cabinet)
Certifications: CE, compliant with industrial DCS standards

Applications

Digital on/off output control of S800 I/O station for ABB System 800xA DCS system.
Driving solenoid valves and relays in process industries such as chemical, oil & gas, power plant and water treatment.
Remote control of equipment start/stop, valve on/off and field indicator lights on production lines.
DCS system expansion, spare parts replacement and I/O unit maintenance for large plants.
On-off actuator control for process control equipment in metallurgy and paper-making industries.
