ABB PFVO102 3BSE023732R1 Fieldbus Fiber Conversion Module

ABB PFVO102 3BSE023732R1 Fieldbus Fiber Conversion Module

Part Number: PFVO102 3BSE023732R1
Product Type: SSI Synchronous Serial Interface – Speed Measurement Interface Card, mainly used for generator / turbine speed measurement collection, and belongs to the spare board card of UNITROL excitation system.

Key Technical Parameters Table

| Project | Specification
| Interface Type | SSI (Synchronous Serial) Speed Sensor Input |
| Power Supply | DC 24V (12-36V wide range), with reverse polarity protection |
| Speed Measurement Range | 0-10000 RPM, resolution 0.01 RPM, accuracy ±0.05% FS |
| Signal Update | <1ms high-speed acquisition, supports self-diagnosis alarm for sensor breakage |
| Electrical Isolation | Channel isolated from the system by 1500V DC |
| Operating Temperature | -20℃ ~ +70℃ |
| Installation | Backplane card type (rack-mounted), not DIN rail |
| Application Scenarios | UNITROL excitation system, generator speed feedback, turbine speed monitoring, closed-loop control of rotating equipment speed

 Compatibility and Instructions

1. System Compatibility: ABB UNITROL Excitation Platform**, used to collect SSI encoder/velocity sensor signals and send them to the excitation controller for speed closed-loop, excitation loss protection, and speed limit logic.
2. Material Characteristics of the Same Series: Belongs to the ABB **3BHE××R0001** excitation board card family. The board card is of a PCB insert card structure and is directly inserted into the system backplane, not an external independent module.
