ABB PP874 Order Number 3BSE069271R2 (Panel 800 V6 7-inch DCS operation touch screen)
I. Basic Identification
Model: PP874
Material Code: 3BSE069271R2 (R2 is the 2nd generation of the hardware version, compatible with 800xA/Freelance DCS)
Product Series: ABB Panel 800 Version 6 Industrial Human-Machine Interface HMI
Compatible System: ABB Ability System 800xA, Freelance DCS, dedicated operation panel for power plants/chemical process control
Display and Touch Core Parameters
Screen Specifications
Size: 7-inch wide-screen TFT LCD
Resolution: 800×480 (16:9), 64000 colors
Brightness: 350 cd/m², backlight lifespan 20,000 hours
Viewing Angle: Horizontal 140° / Vertical 130°
Touch: 4-wire resistive touch screen, industrial resistant to oil, moisture conditions
Shell: Powder-coated aluminum alloy casing, total net weight 0.8kg
Opening Installation Dimensions: 204 (W) × 143 (H) × 49 (D) mm, control cabinet embedded installation
Electrical Power Supply
Power Supply: DC24V (18～32VDC wide voltage)
Overall Power Consumption: Typical 6W
Built-in 2A DC fuse, built-in BR2032 lithium battery (storage time, engineering parameters)
Auxiliary Power Output: 24VDC/0.5A, can supply power to on-site small sensors eero
All Communication Interfaces (Backside)
RJ45 Ethernet: Connect to 800xA controller, TCP/IP, OPC UA, Modbus TCP
2×RS232 Serial Ports: Modbus RTU, third-party instrument / frequency converter communication
USB2.0 Host: USB drive for engineering download, data export, firmware upgrade
Expansion Terminal: Optional IO module (DI/DO/AI/AO local signal acquisition)
Protection and Environment
Front Panel Protection: IP65/IP66 (dust-proof, waterproof splash-proof)
Back Body: IP20
Operating Temperature: -10℃ ~ +60℃
Storage Temperature: -20℃ ~ +70℃
Certification: CE, UL/cUL, RoHS, meets industrial strong EMC anti-interference standards eero
Software and System Compatibility
Configuration Software: Panel Builder 800 (配套 800xA control platform)
Native Protocols： ABB Comli， Modbus TCP/RTU， OPC， perfect linkage with AC800M controller
Functions： Process screens， trend curves， alarm records， SOE events， parameter setting， user permission classification
Multi-Unit Networking： Multiple PP874 share controller real-time data through Ethernet
