product description
Model: PP881
Order Number: 3BSE092978R1
Series: ABB Panel 800 Standard Process HMI Touch Screen
Compatible System: System 800xA / AC800M DCS/PLC System
Position: 10.1-inch industrial human-machine operation panel, replacing the old PP877
Origin: Thailand
Screen and Display Parameters
Size: 10.1 inches, 16:9 wide screen TFT LED backlight
Resolution: 1024 × 600
Touch: Resistive industrial touch screen
Graphics: Vector graphics library, supports trend curves, alarms, flowcharts, reports, multi-language switching
Hardware Mechanical Specifications
Power Supply: DC24V, total system power consumption 21.6W
Overall System Dimensions: 292 × 194 × 52 mm
Control Cabinet Hole Dimensions: 275 × 177 mm
Installation: Panel embedded installation, compatible with VESA 75×75 wall mounting
Net Weight: Approximately 1.65 kg
Protection Grade: Front panel IP65 / NEMA4X; Back panel IP20
Environmental Conditions
Operating Temperature: -10℃ ~ +60℃
Storage Temperature: -20℃ ~ +70℃
Humidity: 5% ~ 85% without condensation
Shell: Cast aluminum alloy powder-coated shell, resistant to oil and dust
Communication Interfaces (Back of the Machine)
1× Ethernet RJ45 (connects to AC800M controller) 1× RS232
1× RS422/485 (COM2 multiplexing)
Supported protocols: ABB OPC, Modbus RTU, OPC UA, can be connected to third-party PLCs
Software configuration requirements
Programming software: Panel Builder 800 V6.2 and above versions
Functions: Offline simulation, trend storage, historical alarm recording, permission classification, recipe management
Companion accessories: RX881 touch screen protection cover; RX800 adapter board (used to replace the old holes of PP877)
Typical application scenarios
Chemical industry, water treatment, power plant System 800xA DCS control room operation screen
Metallurgy, papermaking, cement AC800M PLC monitoring
Oil and gas, energy, pharmaceutical complete automation equipment local operation station
