The ABB PPD513 A23-111615 (3BHE039724R2365) excitation control system is a high-performance excitation controller launched by ABB. The following is a detailed introduction to this system:
I. System Overview
Manufacturer: ABB
Product Type: Excitation Control System
Model Identifier: PPD513 A23-111615 (3BHE039724R2365)
Application Field: Primarily used in the automatic regulation system of power transformers, and also applicable to various types of transformers, including AC, DC and thyristor transformers. It is widely used in power generation, transmission and distribution fields.
System Composition and Functions
Composition: The system usually consists of a controller and an exciter. The controller uses the measured values of the transformer to calculate the required excitation voltage, and the exciter converts the voltage output by the controller into excitation current.
Functions:
Automatic regulation of excitation voltage: To maintain the output voltage of the transformer within the set value, preventing overvoltage or overcurrent in the transformer, and protecting the transformer from faults.
Multiple control modes: Supports various control modes such as constant current, constant power or constant resistance, and can be flexibly switched according to actual needs.
Protection Functions: Equipped with overvoltage, undervoltage, overtemperature, overcurrent and other protection functions to ensure the safe and stable operation of the system.
Technical Specifications and Parameters
Controller Input: Transformer voltage, current, temperature and frequency and other parameters.
Controller Output: Excitation voltage.
Exciter Output: Excitation current.
Rated Voltage: 1000V to 5000V.
Rated Current: 10A to 200A.
Rated Frequency: 50Hz to 60Hz.
Power Supply: 115V – 250V (specific models may vary).
Interfaces and Protocols: Supports various interfaces and protocols to facilitate integration with other devices or systems.
System Advantages and Features
High Reliability: Uses high-quality circuit boards and components to ensure stable performance of the system in various harsh environments.
Precise Control: Achieves precise control of the transformer’s output voltage through advanced control algorithms and precise measurement technology.
Easy Integration: Provides multiple interfaces and protocols support to facilitate integration and communication with other devices or systems.
Intelligent Management: Possesses self-diagnosis, self-protection and other intelligent functions to reduce maintenance costs and improve system availability.
Application Scenarios and Cases
Power Plant: In power plants, this system can be used to control the excitation current of generators to ensure the stability of generator output voltage.
Substation: In substations, this system can be used to control the excitation current of transformers to improve the operating efficiency and stability of transformers.
Industrial Automation: In the field of industrial automation, this system can also be used to control the excitation current of various motors to achieve precise control and energy-saving operation of motors.
