I. Basic Identification Information
Commercial Model: PPD513A0E-110110
ABB Material Code: 3BHE039724R0E41
Product Series: AC 800PEC (High-Performance Closed-Loop Process Controller)
Equipment Function: Dedicated main control module for synchronous generator static excitation (core control unit of the UNIROL excitation system), integrated redundant power supply and high-speed computing mainboard, serving as the central brain of power plant excitation systems

Core Functions of Excitation System (Dedicated to Power Generation Applications)
Specifically designed for excitation and voltage regulation of steam turbine generators and hydroelectric generator sets, replacing traditional excitation regulator hardware:

– Terminal voltage closed-loop control
Real-time acquisition of generator PT voltage and CT current; rapid adjustment of excitation current via PID + Power System Stabilizer (PSS) algorithms to maintain constant generator output voltage and resist grid disturbances and load fluctuations.

– Built-in complete excitation protection logic
Includes over-excitation limit, under-excitation limit, reactive power limit, V/Hz limit, loss-of-field protection, overcurrent protection, and load rejection overvoltage suppression—providing a comprehensive protection system against generator excitation faults.

– Reactive power / power factor control
Supports fixed reactive power or fixed power factor operation to meet grid interconnection dispatch requirements.

– Dual-channel redundancy compatibility
Supports dual-controller redundant hot standby configuration in the excitation system, enabling seamless failover with no interruption, meeting SIL3 safety level requirements for power stations.

 Complete Hardware and Electrical Specifications

1) Integrated Redundant Power Supply (Customized 110VAC version)
– AC input: Wide range 90–264VAC, nominal 110VAC, 50/60Hz
– DC output: 24VDC / 10A, total power 240W, efficiency ≥94%
– Redundancy switching: Dual AC input redundancy, switch time <200μs, zero power interruption
– Protection: Full protection against overvoltage, overcurrent, short circuit, overheating, and reverse polarity

2) Main Control Processing and I/O Channels (Dedicated to Excitation Data Acquisition and Control)
– Architecture: 32-bit CPU + FPGA hardware acceleration, minimum control cycle 25μs, typical 100μs (ultra-fast response suitable for excitation transient regulation)
– Analog channels: 8 AI + 8 AO, ±10V range, 16-bit high-precision sampling, 2kV electrical isolation per channel
– Digital inputs/outputs: 16 DI + 16 DO, used for closing, field extinction, fault alarms, and system status feedback
– Communication interfaces: Dual Ethernet, PROFIBUS DP, fiber-optic high-speed link, RS232/485; supports Modbus TCP and internal fiber bus, compatible with 800xA DCS and backend monitoring systems

3) Environmental and Mechanical Specifications
– Installation: Standard rack-mount plug-in design, supports hot-swapping without shutdown
– Operating temperature: -20°C to +70°C; storage: -40°C to +85°C
– Protection: IP20 (for cabinet installation), G3 corrosion resistance rating, immune to strong electromagnetic interference and vibration, suitable for harsh environments in power station control rooms
– Net weight: ~3.8kg; overall dimensions: 410×286×61mm
– Certifications: CE, UL, TUV, SIL3 safety certification

Typical Application Scenarios
– Static excitation systems for synchronous generator units in thermal and hydropower plants (most mainstream application)
– Compatible with UNIROL series excitation cabinets for medium and small-sized steam and hydro turbine units
– Excitation and voltage regulation for self-owned power plants, waste heat recovery power generation, and biomass power generation units
– Voltage and reactive power regulation for captive power stations in metallurgical steel mills and gas turbine generator sets
– Excitation control systems for grid-side synchronous condensers
