 Product Description

MVTT14R1YB0751E (formerly AREVA Asea, later belonging to GE Vernova), MVAJ Series Permanent Magnet Trip Relay, an electromechanical latch protection relay, is used for trip, signal locking, and fault latch indication in high-voltage switch cabinet protection circuits.

Key Technical Parameters

Table

 Project | Parameter
| Model | MVTT14R1YB0751E
| Series | MVAJ trip and control relay
| Rated coil voltage | 110 – 125 VDC
| Reset method | Manual reset + Electrical reset
| Locking method | Magnetic retention (self-locking after operation)
| Contact configuration | 4 sets of contacts
| Contact closing capacity (3s) | AC 7500VA, DC 7500W, maximum 30A 300V
| Contact continuous closing capacity | AC 1250VA, DC 1250W, maximum 5A 300V
| Contact breaking capacity | AC 1250VA; DC resistive 80W, inductive 40W
| Action time | ≤ 15ms (electrical reset) |
| Operating temperature range | -25℃ ~ +70℃
| Installation form | Plug-in module installation, protection panel rack installation
| Shell | Transparent dust-proof protective shell

Product Performance

1. Magnetic retention latch structure, maintaining the state after the action, it will not reset even without power supply, and records the fault events. Manual or electrical reset is required.
2. Large-capacity contacts, suitable for strong impact loads in circuit breakers’ tripping circuits.
3. Dual repositioning, manual reset on the on-site panel, and also supports remote electrical reset.
4. Transparent housing, allowing for direct observation of the action status indicator flag of the relay.
5. Resistant to shock and vibration, suitable for long-term operation of secondary protection circuits in substations and high-voltage cabinets.
6. Modular plug-in structure, facilitating on-site replacement and maintenance.
