Product Description
ALSTOM SPU232.2, Part No.029.366.817, CAN System Single Processor Board. It acts as core CPU unit for Alspa 6000 control system. OEM production is obsolete, classified as GE Vernova legacy spare part. This board integrates single‑processor core and galvanic‑isolated CAN 2.0B bus interface. It executes system logic operation, signal processing and synchronisation calculation, communicates with rack I/O modules via CAN bus to realise generator synchronisation logic, data acquisition and alarm output.
Technical Specifications
| Item | Specification |
|---|---|
| Full Model | SPU232.2, P/N 029.366.817 |
| Product Type | CAN System Single Processor Board |
| Unit Type | Single Processor Unit (SPU) |
| Communication Interface | CAN 2.0B with galvanic isolation; internal back‑plane bus |
| CAN Baud Rate | Up to 1 Mbps, configurable |
| Core Function | Logic computation, signal processing, synchronisation condition judgement, alarm management, inter‑module CAN‑bus data exchange |
| Power Supply | 24 VDC / 110‑220 VDC (system configurable) |
| Operating Temperature | 0℃～+60℃ |
| Mounting | Plug‑in module for DPUK rack backplane |
| Certifications | CE, IEC 60255, IEEE C37.90, Industrial EMC standard |
| Weight | Approx. 0.4 kg |
| Country of Origin | Germany |
Product Application
- Main controller for Alspa 6000 platform, steam turbine control system for thermal, hydro and gas‑fired power plants.
- Networking with DIZ232, BIO232.1, SSI232.1 and other I/O modules through CAN bus.
- Perform automatic & manual generator synchronisation algorithm, grid‑connection condition check and alarm signal output.
- Aged power‑plant unit retrofit, defective CPU board replacement and spare‑parts inventory.
- Control‑system commissioning, online monitoring and fault diagnostics.
Related Series Models
- SPU232.1‑CAN: Early‑generation CAN single processor unit, P/N 029.354.630, older hardware, partial firmware incompatibility
- SPU232.2‑5: Revised hardware version, P/N 029.366.818, improved CAN interface, backward‑compatible
- ICP232: Companion control processor board for same rack
- CAN232.2: Stand‑alone CAN communication interface board, P/N 029.356.519
- DIZ232: Digital input module
- BIO232.1: Digital output module
- SSI232.1: Analogue signal measurement board
