AMAT 0150-25726 RF Radio Frequency Coaxial Cable

Product Description

Model: AMAT 0150-25726 , RF power cable assembly for Applied Materials semiconductor equipment, OEM spare part. This cable assembly is used for high-frequency power transmission between RF generator and process chamber. It adopts shielded coaxial construction with matched impedance and excellent high-frequency performance. It can withstand high temperature in process environment, reduce RF signal loss and suppress electromagnetic interference. Pre-assembled connectors at both ends enable plug-and-play installation without field crimping, widely used in RF loop of AMAT etch and deposition process tools.

Specifications

• Model: 0150-25726
• Brand: AMAT Applied Materials
• Product Type: RF Coaxial Cable Assembly
• Cable Construction: Shielded coaxial RF cable with pre-terminated connectors
• Characteristic Impedance: 50Ω
• Applicable RF Power: Matched with RF power specification of AMAT tools
• Operating Temperature: 0℃ ~ +85℃
• Storage Temperature: -20℃ ~ +90℃
• Outer Jacket: Plasma-resistant and anti-aging
• Mounting: Internal machine wiring, direct plug-in connectors
• Compatible Tools: AMAT PVD, CVD, Plasma Etch semiconductor process equipment
• Certifications: UL, CE
• Lifecycle: OEM spare part for tool maintenance and replacement

Application

Used in Applied Materials wafer processing equipment including PVD, CVD and plasma etchers. It serves as RF power transmission path to deliver high-frequency power from RF generator to process chamber to sustain plasma process. Aged or damaged cable may cause RF power attenuation, process drift and tool fault alarms. This spare part is used for production line maintenance and replacement to stabilize thin-film deposition and etching processes.

Same Series Models (AMAT RF Cable Spare Parts)

1. 0090-07391
2. 0090-07392
3. 0090-07394
4. 0090-07395
5. 0090-06245
