B&R 8BVI0055HWD0.000-1 Servo Drive Module

Product Description

Model: B&R 8BVI0055HWD0.000-1, ACOPOSmulti 2-axis servo inverter drive module, wall-mounted type. The module integrates two independent power inverter units with safe stop function. It comes with interfaces for motor holding brake and motor temperature sensor. Equipped with 2 expansion slots for optional ACOPOSmulti plug-in modules. It supports POWERLINK real-time industrial fieldbus, built-in short-circuit and earth fault protection. Modular cabinet mounting design enables high-precision multi-axis synchronous motion control.

Specifications

• Model: 8BVI0055HWD0.000-1
• Brand: B&R
• Series: ACOPOSmulti
• Axes: 2 axes
• Continuous output current: 7.6 A
• Rated DC bus voltage: 750 VDC
• Mounting type: Wall mounting
• Protection class: IP20
• Dimension (W×H×D): 53 mm × 317 mm × 263 mm
• Weight: Approx. 2.9 kg
• Operating ambient temperature: 5℃ ~ 40℃ (Max. 55℃)
• Storage temperature: -25℃ ~ 55℃
• Transport temperature: -25℃ ~ 70℃
• Relative humidity: Operation 5~85%, Storage 5~95% (non-condensing)
• Pollution degree: 2; Overvoltage category: III
• Expansion slots: 2 slots for ACOPOSmulti plug-in option modules
• Integrated functions: Safe stop, motor brake interface, motor temperature monitoring, short-circuit protection, earth fault protection
• Certifications: CE, UL/cULus

Application

It is used for automation machinery requiring high-precision multi-axis synchronization: packaging machinery, textile machines, injection molding equipment, metal processing machine tools, material handling production lines, industrial robots and printing machines. This module supports complex motion control functions including electronic cam, flying shear and multi-axis synchronization. It is the preferred solution for small and medium-sized 2-axis servo control. The modular structure facilitates on-site commissioning and system expansion.

Same Series Models (ACOPOSmulti 2-axis Inverter Servo Modules)

1. 8BVI0014HWD0.000-1
2. 8BVI0055HCD0.000-1
3. 8BVI0055HWS0.000-1
4. 8BVI0055HWSS.000-1
5. 8BVI0055HCS0.000-3
