B&R 8BVP0220HW00.000-1 Power Module

Product Description

B&R 8BVP0220HW00.000-1 is an active power supply module of the ACOPOSmulti series. It serves as the central power unit for the ACOPOSmulti multi-axis servo drive system. It accepts wide-range three-phase input and features energy regeneration capability, feeding braking energy back to the mains for high energy efficiency. The module has 2 slots for plug-in option modules and supports Dynamic Node Allocation (DNA). Wall-mounted with IP20 protection class, it builds a complete servo drive system together with inverter modules. It is certified with CE, UL, UKCA and KC.

Parameters

• Order No.: 8BVP0220HW00.000-1
• Brand: B&R (Bernecker + Rainer)
• Series: ACOPOSmulti Active Power Supply Module
• Mains Input: 3×220～480VAC ±10%, 50/60Hz
• Max. installed power: 15.6kW
• DC Bus: Approx. 560V DC in passive mode; approx.750V DC in active mode
• Switching frequency: 5kHz (10kHz optional)
• Option slots: 2 plug-in module slots, DNA supported
• Mounting: Wall mounting
• Protection class: IP20
• Operating temperature: 5℃～40℃, max. 55℃ short-term
• Storage / transport temperature: -25℃～70℃
• Relative humidity: 5~85% during operation, up to 95% @40℃ for storage
• Weight: Approx. 5.2kg
• Certifications: CE, cULus, UKCA, KC

Product Application

It supplies DC bus power to servo inverter modules within the ACOPOSmulti modular multi-axis servo system and returns motor braking energy to the power grid. It is widely used in multi-axis synchronous motion control applications: packaging machinery, textile machines, printing equipment, metal forming machine tools, injection molding machines, robotic manipulators, material handling lines, lithium battery and photovoltaic automation production lines. Ideal for high-end automation machines requiring fast start-stop, frequent braking and high dynamic response.

Similar Series Models

1. 8BVP0220HW00.000-1: Active power supply, 15.6kW (This item)
2. 8BVP0440HW00.000-1: ACOPOSmulti active power supply, 31kW
3. 8BVP0880HW00.000-1: ACOPOSmulti active power supply, 62kW
4. 8B0P0220HW00.000-1: ACOPOSmulti passive power supply, 15.6kW
5. 8B0P0440HW00.000-1: ACOPOSmulti passive power supply, 31kW
