Product Description
8I0IF108.400-1 is a high‑performance industrial inverter of B&R ACOPOSinverter P74 series, rated 7.5 kW for 3‑phase 380‑500 VAC supply. It integrates EMC filter and brake chopper, equipped with POWERLINK real‑time industrial Ethernet interface and shielding plate included in delivery. Supporting V/F control and sensor‑less vector control, it drives asynchronous and synchronous motors for precise speed and torque regulation. Designed for seamless integration with B&R automation system, compact mechanical design, certified with CE, UL and KC for industrial applicationsB& R Indus….
Technical Parameters
| Item | Specifications |
|---|---|
| Product family | ACOPOSinverter P74 |
| Model | 8I0IF108.400-1 (Order code:8I74T400750.01P‑1) |
| Rated power | 7.5 kW (10 HP) |
| Mains input | 3‑phase 380‑500 VAC,‑15%~+10%;50‑60 Hz±5% |
| Input current@380 VAC | 26.5 A |
| Input current@500 VAC | 18.7 A |
| Apparent power @500 VAC | 16.2 kVA |
| On‑board features | Integrated EMC filter, brake chopper, shielding plate |
| Communication | POWERLINK Type3 |
| Output frequency range | 0.1‑599 Hz |
| Protection class | IP20 |
| Operating temperature | ‑10℃~+50℃ (no derating); derating required 50‑60℃ |
| Storage temperature | ‑25℃~+70℃ |
| Safety functions | STO safe torque‑off; over‑current, short‑circuit, over‑voltage, under‑voltage, thermal, phase‑loss protection |
| Certifications | CE, UL, KC |
| Max. short‑circuit current | 22 kA |
| Power dissipation | 263 WB& R Indus… |
Product Application
- Machine tool auxiliary drives: conveyor, cooling pump, auxiliary feed axis
- Packaging automation: conveyor belt, film winding & unwinding mechanism
- Material handling: conveyor, lifting equipment, stacking auxiliary unit
- Textile machinery: roller drive, traction and winding control
- Plastic & rubber machinery: extruder auxiliary, traction conveyor
- General‑purpose industrial fan and pump speed regulation
- Complete machine motion control solution cooperating with B&R Automation Studio
P74 Series Models (010‑1 hardware revision)
8I74T400037.010‑1 (0.37 kW) 8I74T400055.010‑1 (0.55 kW) 8I74T400075.010‑1 (0.75 kW) 8I74T400110.010‑1 (1.1 kW) 8I74T400150.010‑1 (1.5 kW) 8I74T400220.010‑1 (2.2 kW) 8I74T400300.010‑1 (3.0 kW) 8I74T400400.010‑1 (4.0 kW) 8I74T400550.010‑1 (5.5 kW) 8I74T400750.010‑1 (7.5 kW) 8I74T401100.010‑1 (11 kW) 8I74T401500.010‑1 (15 kW)B& R Indus…
