B&R 8I74T400750.010‑1 P74 Series High Performance Frequency Converter

Product Description

B&R 8I74T400750.010‑1 is a high‑performance frequency inverter from the ACOPOSinverter P74 series with nominal power of 7.5 kW for three‑phase 380‑500 VAC supply. It integrates built‑in EMC filter and brake chopper, equipped with POWERLINK real‑time industrial Ethernet interface and STO Safe‑Torque‑Off safety function. Supporting sensor‑less vector control and V/F control modes for asynchronous motors, it delivers precise speed and torque regulation. Digital & analog I/O channels are provided, parameters can be set via local panel or engineering software. DIN‑rail cabinet‑mount design, manufactured in Austria. Deployed as drive unit for machinery OEM integration, spare‑part replacement and production‑line retrofitting projects.

Technical Specifications

1. Model: 8I74T400750.010‑1; Series: ACOPOSinverter P74
2. Rated Power: 7.5 kW
3. Mains Input: 3‑phase 3×380‑500 VAC,‑15% / +10%; 50‑60 Hz
4. Rated Input Current: 26.5 A @380 VAC, 18.7 A @500 VAC; Apparent power 16.2 kVAB& R Indus…
5. On‑board Features: Integrated EMC filter, brake chopper, STO Safe‑Torque‑Off
6. Communication: POWERLINK real‑time Ethernet; standard digital / analog I/O
7. Control Modes: V/F control, sensor‑less vector control; output frequency 0‑500 Hz
8. Protections: Over‑current, over‑voltage, under‑voltage, over‑temperature, short‑circuit, motor PTC thermal protection
9. Certifications: CE, UL, KC industrial approvalsB& R Indus…
10. Mounting: DIN‑rail cabinet installation; shielding plate included
11. Operating Temperature: 0℃‑+55℃; Storage Temperature‑25℃‑+70℃
12. Max. Assumed Short‑circuit Current: 22 kAB& R Indus…

Product Applications

1. Asynchronous‑motor drives for packaging, textile and material‑handling machinery
2. Variable‑speed control for fans and pumps for flow & pressure regulation
3. Production‑line automation within POWERLINK‑based integrated drive systems
4. Variable‑frequency drive units for rubber‑plastic and printing machines
5. Spare‑part replacement for B&R P74 inverters and legacy‑equipment retrofits
6. Factory automation interfaced with B&R X20 control system for complete machine motion‑control solutions

Peer Series Part Numbers

1. 8I74T400400.010‑1 (4.0 kW)
2. 8I74T400550.010‑1 (5.5 kW)
3. 8I74T401100.010‑1 (11 kW)
4. 8I74T401500.010‑1 (15 kW)
