Foxboro 760CSA-3A 760 Series Single-Station Micro Process Controller

Product Description

Foxboro 760CSA-3A is a Single Station Micro Controller of the 760 series, shelf-mount type with PID closed-loop regulation for single-loop industrial process control. The code represents a 30-pin quick-disconnect signal connector and 120V AC 50/60Hz power supply. It accepts analog inputs such as 4-20mA, equipped with analog control output and discrete I/O. It supports setpoint adjustment, alarm and retransmission output. With solid and stable construction, it is widely used for independent loop regulation in chemical, oil & gas, power plant and other process industries.

Product Parameters

• Series: 760 Series Single Station Micro Process Controller
• Model: 760CSA-3A
• Mounting: Shelf Mount
• Signal Connector: 30-pin quick-disconnect connector
• Power Supply: 120V AC, 50/60Hz
• Analog Input: 4-20mA DC, 1-5V DC, pulse/frequency signal
• Analog Output: 4-20mA DC control output; 1-5V DC auxiliary retransmission output
• Discrete Input: 2 contact / transistor switch inputs
• Discrete Output: 2 open collector outputs, max 50V DC, 250mA
• Control Algorithm: PID regulation
• Functions: Loop PID control, parameter setting, process alarm, variable retransmission
• Compatible Shelf: 202S series shelf
• Certifications: CE, UL, compliant with industrial process control standards

Product Application

Used for single-loop closed-loop control in process industry to realize PID automatic regulation of temperature, pressure, level, flow and other process variables. Typical industries: oil & gas, chemical, power, water treatment, paper making. It can work independently as a single loop controller without large DCS system. Suitable for small & medium independent control loop retrofit and local field regulation. Output signal drives valve actuators, and transmits process variables for monitoring.

Same Series Models (760/761 Series Controller)

760CSA-2A, 760CSA-3B, 760CSA-3C, 760CSA-3D, 760CSA-3E, 761CSA-3A, 761CSA-3B
