Foxboro RH101AB I/O module

Product Description

Model: Foxboro RH101AB, Brand Foxboro (owned by Schneider Electric), I/A Series DCS Termination Assembly (TA). It works with FBM fieldbus I/O modules. This terminal unit receives field instrument signals and performs signal distribution & conversion. Mounted directly on FBM baseplate, it transmits 4-20mA analog and discrete signals from field instruments to I/O modules. It adopts spring-cage terminals for convenient wiring and supports HART communication with circuit open/short detection. It is an essential wiring component inside Foxboro I/A DCS control cabinets, widely used for spare parts replacement of legacy DCS projects.

Specifications

• Model: RH101AB
• Brand: Foxboro (Schneider Electric)
• Series: I/A Series DCS
• Product Type: Termination Assembly (TA)
• Compatible Module: FBM series I/O modules
• Wiring Type: Spring-cage terminals
• Supported Signals: 4~20mA analog, discrete digital, superimposed HART signal
• Power Supply: 24VDC loop power (external power source)
• Mounting: Baseplate mounting / DIN rail mounting
• Protection Class: IP20 (inside control cabinet)
• Operating Temperature: 0℃ ~ +60℃
• Storage Temperature: -40℃ ~ +85℃
• Certifications: CE, UL
• Lifecycle Status: Discontinued, spare parts for power & chemical legacy projects

Application

Deployed in Foxboro I/A DCS control cabinets for oil & gas, chemical, power and pulp & paper industries. As matched terminal assembly for FBM I/O modules, it connects field transmitters, valve positioners and switches to collect and output process signals. It supports HART digital communication for instrument commissioning and parameter reading. It is used for maintenance, spare part replacement and partial retrofitting of old DCS systems to ensure reliable acquisition of field process signals.

Same Series Models (RH101 Termination Assembly Series)

1. RH101AA
2. RH101EY
3. RH101KA
4. RH101RP
5. RH101XE
