Product Description
F2DO801 (Part No. 982200481) is a safety digital output module from German HIMA HIMatrix F2 series. It is certified SIL3 per IEC61508 and PL e per EN ISO13849-1. This module has 8 independent passive normally-open safety relay contacts. It communicates with HIMatrix and HIMax safety controllers via SafeEthernet to control field safety actuators such as solenoid valves and emergency shutdown valves. Comprehensive channel diagnostics detect open circuit, short circuit and load faults. Outputs automatically switch to de-energized safe state on fault, with LED indicators for channel status and fault alarm. It adopts standard 35mm DIN rail mounting, serving as core safety I/O spare parts for ESD emergency shutdown systems and F&G fire & gas systems.
Data Sheet
| Item | Specification |
|---|---|
| Model | F2DO801 |
| Part Number | 982200481 |
| Series | HIMatrix F2 Series |
| Type | Safety Digital Output Module, DO |
| Safety Certification | SIL3 (IEC61508 / IEC61511), PL e (EN ISO13849-1) |
| Output Channels | 8 independent relay passive normally-open contacts |
| Contact Rating | Max. 250VAC / 250VDC, 3A (resistive load) |
| Communication Interface | 2 × RJ45 SafeEthernet, 10/100Base-T |
| Power Supply | 24VDC, operating range:19.2V ~ 30V DC |
| Operating Temperature | 0℃ ~ +60℃ |
| Storage Temperature | -40℃ ~ +85℃ |
| Relative Humidity | 5% ~ 95%, non-condensing |
| Diagnostics | Open/short circuit & load fault detection; auto switch to safe state |
| Mounting | 35mm DIN rail mounting |
| Protection Class | IP20 (module body) |
| Dimension (H × W × D) | 114 × 207 × 86 mm |
| Weight | Approx.1.3kg |
| Origin | Germany |
Product Application
It is used for Oil & Gas ESD emergency shutdown systems and F&G fire and gas systems; safety interlock loops in chemical plants; safety protection for power plant boilers and turbines; pipeline safety shutdown control and other high-risk applications. It drives safety shutdown valves, solenoid valves, sound & light alarm circuits and other safety actuators. Suitable for HIMA safety system expansion and on-site faulty spare replacement.
