HIMA F7126 990001110 Isolation power module

Product Description

HIMA F7126 (Order No:990001110) is an isolated rack-mounted DC/DC power supply module for HIMA H41q / H51q programmable electronic safety system (PES) from Germany HIMA. It serves as the core power unit of SIS safety instrumented systems. This module converts 24VDC input into isolated 5VDC power for rack backplane, supplying power to CPU and I/O cards. It is equipped with galvanic isolation between input and output, current limiting, overvoltage and short-circuit protection. Redundant parallel operation is supported, certified to IEC61508 SIL3. It is widely used as spare part for safety interlock systems in chemical, oil & gas and power plants.

Specifications

1. Model: F7126; Order No:990001110
2. Product Type: Rack-mounted Isolated DC/DC Power Supply Module
3. Compatible System: HIMA H41q / H51q PES safety rack
4. Input Voltage: 24VDC, tolerance -15% ~ +20%, ripple Rpp＜15%
5. Output Voltage: 5VDC (continuously adjustable ±0.5V, factory preset at 5.4VDC±0.025V)
6. Rated Output Current: 10A; Current Limit: approx.13A
7. Overvoltage Protection Threshold: 6.5V±0.5V, short-circuit proof output
8. Efficiency: ≥77%
9. Isolation: Galvanic safety isolation between input and output
10. Main Fuse: 6.3A slow-blow fuse
11. Mounting: 8TE Eurocard rack slot mounting
12. Front Panel: Voltage adjustment potentiometer, test socket
13. Safety Level: IEC61508 SIL3
14. Operating Temperature: 0 ~ +60℃ (inside cabinet)
15. Storage Temperature: -40 ~ +85℃
16. Protection Class: IP20 (PCB module installed inside control cabinet)
17. Certifications: TÜV, CE

Applications

• Oil & Gas: Power supply for SIS safety instrumented systems on offshore platforms and long-distance pipelines
• Petrochemical: ESD emergency shutdown systems and interlock protection racks for chemical plants
• Power Industry: Safety protection systems for boilers and turbine units in thermal & captive power plants
• Coal Chemical: Safety interlock systems for ammonia and methanol plants
• Maintenance: Replacement of faulty power modules for HIMA H41q/H51q systems, spare parts for plant overhaul
• Retrofit: Upgrade of legacy SIS systems and redundant power expansion projects

Family Models

F7128 24V Power Supply Module F7130 F7131 F7133 F8101 F8110
