Honeywell 900P24-0301 Power Module

Product Description

Honeywell 900P24-0301 is a rack-mounted DC/DC power supply module for Honeywell ControlEdge HC900 PLC system. It converts 21~29VDC input and supplies stable 5VDC and 24VDC power to rack controllers and I/O cards with rated output power of 60W. Equipped with overcurrent, short-circuit and over-temperature protection, plus power status LED indicators. It supports redundant rack configuration. This model is being phased out and replaced by 900P24-0501, mainly used for spare parts replacement and maintenance of existing HC900 PLC systems.

Technical Parameters

• Model: 900P24-0301
• Type: DC/DC Rack Power Supply Module
• Compatible System: Honeywell ControlEdge HC900 PLC
• Input Voltage: 21 ~ 29 VDC
• Input Power Rating: 72.5W
• Output Rating: 60W (Dual outputs: 5VDC & 24VDC)
• Inrush Current: 30A for 3ms @29VDC
• Hold-up Time: 20ms at maximum load
• Terminals: Screw terminals for #12~22AWG wire
• Fuse: Internal non-replaceable fuse
• Protection: Short-circuit, overload and over-temperature protection
• Operating Temperature: 0℃ ~ +60℃
• Mounting: Hot-pluggable rack card
• Features: Power status LED, redundant power supply compatible
• Product Status: Legacy model, available as spare part

Product Applications

1. Rack power supply for Honeywell ControlEdge HC900 PLC, feeding controllers, local I/O modules and remote I/O scanner cards.
2. Process industries including chemical, oil & gas, water treatment and paper-making automation control systems.
3. Redundant power configuration for control racks to improve power reliability.
4. Spare parts replacement, maintenance and retrofitting for existing HC900 automation projects.
5. Rack power unit for small DCS and PLC control cabinets.

Series Models

• 900P24-0301: Standard DC/DC power supply for HC900 rack
• 900P24-0401: SIL rated DC/DC power supply
• 900P24-0501: Replacement upgraded model for 900P24-0301 with G3 conformal coating
• 900P24-0601: Upgraded SIL version for 900P24-0401 with G3 coating
• 900P01-0301: AC/DC power supply of the same series (AC input variant)
