I. Basic Parameters
Model: LG1093AC01
Product Type: Geiger-Müller type ultraviolet flame probe, specifically designed for monitoring the flames of gas turbines and boilers
Cable Configuration: Standard 9 feet (approximately 2.74 meters) double-core stainless steel armored shielded cable
Detection Band: 180~260nm (day-blind ultraviolet band, unaffected by visible light, sunlight, high-temperature infrared)
Standard Power Supply: DC20~35V (rated 28VDC), also compatible with 115VAC power supply specification
Response Time: Typical 0.1~0.2 seconds, rapid detection triggered upon flame extinction
Maximum Transmission Distance: The probe can transmit up to 305 meters (1000 feet) between the probe and the flame amplifier
Operating Temperature: -40℃ ~ +85℃, resistant to vibration, high temperature, dust, and salt fog
Explosion-proof Certification: FM, CE, ATEX explosion-proof certification, suitable for hazardous explosion-proof areas in petrochemical and power plant applications
Installation Interface: Flange outer diameter 1.73 inches, standard furnace flange installation structure
Core Working Principle
Only captures ultraviolet radiation from the combustion of hydrocarbon fuels, a day-blind sensor:
Sunlight, furnace high-temperature infrared, workshop lighting, and electric welding strong light will not cause false detection
The internal phototube of the probe converts the ultraviolet signal of the flame into a weak electrical signal, which is transmitted through the armored cable to the EG1033 flame amplifier module inside the control cabinet
The amplifier processes and outputs switch quantity / analog quantity signals to FSSS, turbine control system, to achieve flameout protection, ignition detection, and re-ignition interlock trip, preventing gas explosion accidents
Core Functions
Ignition Phase: Detects whether the ignition gun and main burner flames have been successfully ignited
Normal Operation: Continuously monitors the presence of the flame in real time. Once the flame goes out, it immediately triggers the emergency cut-off of the fuel valve
Strong Anti-interference: Eliminates false alarms and interlocks caused by strong light, high-temperature smoke, and electromagnetic interference
Long-distance stable signal transmission, suitable for large-scale gas turbines, power plant boilers with long-distance installation scenarios
IV. Differences of the Same Series Models Table
Model Length of Cable Specification
LG1093AC01 9 feet (2.74m) Standard short-distance installation, most commonly used model
LG1093AC05 24 feet (7.32m) Extended cable for furnace remote installation
LG1093AA/AB Flange specifications vary Compatible with old GE gas turbine installation interfaces
Typical Application Scenarios
Flame detection probes for GE series gas turbines of thermal power plants and combined cycle power plants
FSSS furnace safety monitoring systems for industrial coal-fired boilers and gas boilers
Combustion systems for heating furnaces, incinerators, and self-owned power stations in oil and gas fields in petrochemical plants
Flame safety monitoring for offshore platforms and ships with gas-powered generators
