Product Overview
HONEYWELL RM7823A1016 is a microprocessor-based integrated flame switch and burner controller of Honeywell 7800 series, serving as the core safety control component for industrial boilers and combustion equipment. It supports multiple flame detection modes including rectification, ultraviolet (UV) and infrared (IR). Equipped with a high-precision microprocessor system, it automatically completes combustion sequence control, real-time flame monitoring, fault diagnosis and safety interlock protection. Compared with traditional mechanical control modules, it features higher control accuracy and operational stability.
Equipped with two standard SPDT relay outputs, it can be matched with 7800 series amplifiers to expand control functions. Built-in professional anti-electromagnetic interference design enables stable operation under harsh industrial conditions with high temperature, dust and strong electromagnetic interference. Supporting Modbus RTU communication, it connects with upper control systems for data uploading, status monitoring and remote operation and maintenance. It is widely applied in various industrial single-burner gas and fuel combustion equipment, acting as an original core spare part for safe start-stop, flame monitoring and fault protection of industrial combustion systems.
2. Technical Parameters
|
Parameter
|
Specification
|
|
Model Number
|
RM7823A1016
|
|
Product Type
|
Microprocessor-based integrated flame switch & burner controller
|
|
Rated Voltage
|
120 VAC, 50/60Hz (±10% tolerance)
|
|
Max Power Consumption
|
≤10W
|
|
Flame Detection Mode
|
Rectification, UV, IR multi-mode compatible
|
|
Relay Output
|
2-channel SPDT relay output
|
|
Communication Protocol
|
RS485 Modbus RTU
|
|
Response Time
|
Less than 0.1 seconds for flame fault response
|
|
Operating Temperature
|
-20℃ ~ +55℃
|
|
EMC Standard
|
Compliant with IEC 61000 industrial electromagnetic compatibility standard
|
|
Certification
|
CE, UL, FM safety certification
|
|
Matching Accessories
|
Compatible with 7800 series amplifiers, bases and purge timers
|
|
Origin
|
Original USA imported
|
3. Product Features
-
Multi-mode Flame Detection: Compatible with three mainstream detection modes (rectification, UV, IR), suitable for gas and fuel combustion equipment with strong universality.
-
High-level Safety Protection: Microprocessor intelligent calculation realizes millisecond-level flame fault response, quickly identifying flameout, false flame and unstable flame to trigger interlock protection and avoid deflagration risks.
-
Excellent Industrial Anti-interference Performance: Complying with IEC industrial EMC standards, it resists strong on-site electromagnetic interference and voltage fluctuation, ensuring stable operation without false alarms under high temperature and dust conditions.
-
Intelligent Communication & O&M: Modbus RTU communication supports real-time uploading of combustion status, fault codes and operating parameters, realizing remote monitoring and fault tracing to reduce operation and maintenance difficulty.
-
Powerful Modular Expandability: Compatible with Honeywell 7800 series amplifiers and timing modules to expand control functions, adapting to combustion systems of different power levels.
-
Self-diagnosis & Fault Tolerance: Built-in self-test program supports power-on self-inspection and real-time operational monitoring, accurately locating faults and reducing equipment downtime rate.
-
Convenient Installation & Adaptation: Standard industrial structure supports embedded and wall-mounted installation with simple wiring and convenient debugging, ideal for new installation and renovation of old equipment.
