I. Product Description
Y-3023-2-H00AA is a RELIANCE Ryan Electric original incremental rotary encoder, specifically designed for Ryan’s DC speed regulation, high-voltage frequency conversion, and servo drive motors. It collects real-time motor speed and rotor position pulse signals, and feeds them back to the main control board to achieve precise speed closed-loop and vector torque control. It is the core sensing component for speed measurement and positioning in the transmission system.
Key Technical Parameters
Signal Type: A/B/Z three-phase incremental pulse output
Power Supply Voltage: 5VDC
Output Mode: Long-line drive differential signal
Standard Pulse Resolution: 1024P/R
Shaft Diameter Specification: Solid standard motor matching shaft
Protection Grade: IP64
Operating Environment Temperature: -20℃~+70℃
Installation Form: Flange coaxial direct connection to the motor tail
Cable Configuration: Shielded anti-interference dedicated signal line
Product Performance
Differential long-line drive output, resistant to electromagnetic interference and harmonic interference in the cabinet, with no distortion in long-distance transmission of pulses
High-precision pulse scale, ensuring stable speed at low speeds, high-precision speed regulation and stable torque output
Metal reinforced enclosure, sealed protection, suitable for dust, oil contamination, and high-vibration conditions in metallurgical mines
Precise positioning of the Z-phase zero position mark, meeting the requirements of starting, phase change, and synchronous control
Long-life bearing structure, capable of withstanding 24-hour continuous high-speed rotation, with low failure rate
Standard Ryan installation dimensions, with interchangeable replacement for the same series encoders
Application Domains
RELIANCE 7000 Series DC Four-Quadrant Speed Regulation Device
SR3000, VZ7000 High-Voltage Frequency Conversion Transmission Motors
Metallurgical rolling mills, mine hoists, large fans and water pumps main drive motors
Heavy-duty servo drive, large-power speed regulation motor systems for production lines
V. Similar Series Models
Y-3023-1-H00AA: Low-pulse basic model encoder
Y-3023-3-H00AA: High-pulse high-precision version
Y-3024 Series: Hollow shaft compatible encoder
Matching main control acquisition board: Ryan speed feedback signal receiving substrate, compatible with the entire set of 45C992 power supply, S-D series drive board system
