Schneider Electric ATV71HC16N4 Reversing frequency converter

Product Description

Schneider Electric ATV71HC16N4 is a high-performance heavy-duty variable speed drive of Altivar 71 (ATV71) series, rated for 160kW (250HP) 3-phase asynchronous motors with 380~480V 3-phase power supply. It is built-in with Class A EMC filter and graphic HMI panel. It supports sensorless and closed-loop flux vector control, delivering peak 220% overload torque for short duration and maintaining high low-speed torque. It integrates STO Safe Torque Off and rich programmable logic, compatible with various optional fieldbus cards for high-shock and high-starting-torque heavy machinery. Certified to CE and UL. This model is discontinued, commonly used as spare replacement, recommended replacement ATV930C16N4.

Product Parameters

• Series: Altivar 71 High-performance VFD
• Model: ATV71HC16N4
• Device Type: 3-phase heavy-duty variable frequency drive
• Rated Motor Power: 160kW / 250HP
• Input Power: 3-phase AC 380~480V, -15% ~ +10%, 50/60Hz
• Built-in: Class A EMC filter, graphic terminal panel
• Control Modes: V/F, sensorless flux vector, closed-loop flux vector control
• Overload Capacity: 170% nominal torque for 60s, peak 220% for 2s
• Max Output Frequency: 1600Hz
• Safety Function: STO Safe Torque Off
• Communication Options: Modbus, Profibus, EtherNet/IP, CANopen and more
• Motor Cable: Max 100m shielded cable, max 200m unshielded cable
• I/O: Multi-channel programmable digital & analog I/O
• Cooling: Forced air cooling
• Protection Class: IP20 (cabinet mounting)
• Operating Temperature: 0℃ ~ +40℃, derating required at higher temperature
• Certifications: CE, UL
• Lifecycle: Discontinued, spare parts & surplus stock available, end of service on 2028-12-31

Product Application

Designed for heavy-duty and high-dynamic industrial machinery, including cranes, crushers, extruders, heavy mixers, conveyors, fans & pumps, paper and metallurgical production lines. It precisely regulates motor speed and torque to handle load shocks, while STO protects personnel during maintenance. It can connect to PLC/DCS for remote speed adjustment and monitoring. Widely deployed in petrochemical, mining, building material and paper industries for legacy production line retrofit and failed drive spare replacement.

Same Series Models (ATV71 High Power Drives)

ATV71HC11N4, ATV71HC13N4, ATV71HC16N4, ATV71HC20N4, ATV71HC25N4
