Description
Schneider ASCO H9290KCF0C00, solenoid operator assembly for ASCO automatic transfer switch (ATS). It is an OEM spare part dedicated for ASCO H‑Frame ATS units. When energized, the solenoid drives the mechanical mechanism to complete power transfer between normal source and emergency generator source. Assembly includes solenoid coil, mounting base and wiring terminals, being the key actuation component of ATS switch。
Main Specifications
- Product Type: ATS Solenoid Operator Assembly
- Family: ASCO H9290 series spare parts for H‑Frame ATS
- Function: Mechanism driving for source transfer (Normal ↔ Emergency)
- Compatible Unit: ASCO H‑Frame ATS, 800‑1200A frame size
- Coil Voltage: Code K = 415 VAC, 50Hz
- Mounting: Direct drop‑in replacement
- Operating Environment: Indoor power distribution cabinet, industrial site
- Lifecycle: Legacy service spare part; some parent ATS models are discontinued, mainly for after‑sales replacement.
Applications
- Maintenance & replacement for ASCO H‑Frame ATS in industrial power distribution, data centre, hospital and building emergency power supply system.
- Spare part for dual‑power transfer equipment with backup generator; drive switch transfer to generator supply upon utility failure.
- Retrofit and spare‑parts stock for ageing ASCO H‑Frame ATS installations.
