Product Description
Schneider Sepam M41 is a medium-voltage motor integrated protection relay of Sepam Series 40 (Part No.59685). It is dedicated for medium & high voltage induction motors, integrating protection, metering, monitoring, disturbance recording and logic control. It provides comprehensive motor protection functions including thermal overload, locked rotor protection, start limitation, negative sequence unbalance protection and directional earth fault protection. Up to 16 RTD inputs are available for stator and bearing temperature monitoring. Equipped with front HMI, built-in Modbus communication and logic equation editor, it supports circuit breaker / contactor control, event logging and fault waveform recording. Commercial production ended at the end of 2024, OEM service support lasts until 31 Dec 2030. New surplus, refurbished and used spare parts are available on market for maintenance replacement of MV motor control cabinets in power plants and petrochemical plants.
Specifications
- Brand: Schneider Electric
- Model: Sepam M41 (Series 40, PN:59685)
- Type: Medium Voltage Motor Integrated Protection Relay
- Protection Functions: Thermal overload 49RMS, overcurrent 50/51, earth fault 50N/51N, directional earth fault 67N, locked rotor 48, start limitation 66, negative sequence unbalance 46, undercurrent 37, overvoltage / undervoltage, frequency protection
- Analog Inputs: 4 current inputs, 3 voltage inputs, max.16 RTD temperature inputs
- Digital I/O: 10 logic inputs, 8 relay outputs
- Communication: Modbus, optional TCP/IP Ethernet
- Auxiliary Supply: 110~240V AC / 24~250V DC
- Protection Rating: Front panel IP52, rear IP20
- Mounting: Panel flush mounting
- Certifications: CE, UL
- Lifecycle Status: Discontinued; OEM service support until 31 Dec 2030; new surplus, refurbished & used spare parts available
Application
Applied for protection of medium-voltage high-power motors in power plants, petrochemical, water treatment, mining and heavy industry, such as compressors, fans, pumps and mills. It continuously monitors current, voltage, power, energy, winding and bearing temperature. It trips rapidly in case of overload, locked rotor, earth fault, phase loss or phase unbalance, records fault events & waveforms, delivering motor protection, condition monitoring, remote data transmission and switchgear control.
Similar Series Models
- Sepam M20: Sepam Series20, basic MV motor protection with 8 RTD
- Sepam S40: Series40, feeder protection relay
- Sepam T40: Series40, transformer protection relay
- Sepam G40: Series40, generator protection relay
- Sepam M87: Advanced motor relay with motor differential protection
