Schneider Sepam S42 59682 Circuit Breaker Integrated Protection Relay

Product Description

Schneider Sepam S42 is a medium-voltage feeder protection relay of Sepam Series 40, part number 59682, dedicated for substation incomer and feeder circuits. It is the upgraded version of S41, equipped with full voltage and frequency monitoring functions on top of directional phase overcurrent and directional earth fault protection. It integrates protection, metering, energy measurement, event logging, disturbance recording and logic control. It comes with front HMI, built-in Modbus RTU, optional Ethernet extension and logic equation editor, supporting circuit breaker control and fault data storage. Discontinued in Jan 2024, OEM technical support is available until the end of 2030. New surplus, refurbished and used spare parts are available on market for maintenance replacement of MV switchgears in power plants and petrochemical plants.

Specifications

• Brand: Schneider Electric
• Model: Sepam S42 (Series 40, PN:59682)
• Type: Medium Voltage Incomer & Feeder Integrated Protection Relay
• Protection Functions: Phase overcurrent 50/51, earth fault 50N/51N, directional phase overcurrent 67, directional earth fault 67N, undervoltage 27, overvoltage 59, frequency protection 81, negative sequence unbalance 46, breaker failure 50BF
• Analog Inputs: 4 current inputs, 3 voltage inputs
• Digital I/O: 10 logic inputs, 8 relay outputs
• Communication: Modbus RTU, optional TCP/IP Ethernet module, IEC60870-5-103 supported
• Auxiliary Supply: 24~250V DC / 48~230V AC
• Measurement: Current, voltage, active/reactive power, power factor, energy, frequency
• Protection Rating: Front panel IP52, rear IP20
• Mounting: Panel flush mounting
• Certifications: CE, UL
• Lifecycle Status: Discontinued Jan 2024, OEM support until end of 2030; new surplus, refurbished & used spare parts available

Application

Deployed in power plants, petrochemical, mining, water treatment and industrial parks for MV substation incomers, feeders and bus tie protection. It continuously monitors line current, voltage, frequency and energy. It trips rapidly for short circuit, overload, earth fault, abnormal voltage and frequency deviation, records fault events and waveforms, supports fault location and remote SCADA communication to guarantee safe and stable operation of medium voltage distribution network.

Similar Series Models

1. Sepam S40: Basic feeder relay with directional earth fault
2. Sepam S41: S40 plus directional phase overcurrent protection
3. Sepam T40: Series40 transformer protection relay
4. Sepam M41: Series40 medium voltage motor protection relay
5. Sepam G40: Series40 generator protection relay
6. Sepam S52: Advanced feeder relay with fault locator
