Product Description
The WOODWARD 5466-1047 is a core CPU processing module of the MicroNet Plus 5466 series produced by the American Woodward (now part of BorgWarner) company. It belongs to the 5200 series of high-speed speed control units. This module is the “brain” of the entire MicroNet Plus control system, responsible for real-time collection of signals such as rotational speed, load, temperature, and pressure, executing PID regulation algorithms, and outputting control instructions to drive servo valves, frequency converters, or actuators, thereby achieving precise speed and load control for rotating machinery such as gas turbines, diesel generator sets, and steam turbines.
5466-1047 is equipped with 3072K (3MB) user memory, featuring a 1.0GHz quad-core RISC processor, supporting up to 8 I/O module expansions. It is equipped with various communication interfaces such as Ethernet, RS-232/RS-485, Profibus, etc., and can seamlessly integrate into DCS, SCADA or upper-level monitoring systems. This module is widely used in industrial fields such as power, petrochemical, metallurgy, and shipping, and is currently one of the most popular medium and large-sized speed control controllers in the global market.
Technical Specifications
Processor: 32-bit RISC processor, with a main frequency of 1.0GHz and a quad-core architecture
User memory: 3072K (3MB) RAM + Flash
Maximum I/O points: 8192 points
Maximum PID loop count: 512
Maximum alarm count: 512
Ethernet: 10/100 Base-T, RJ45 interface
Serial port: RS-232C (DB9 male), RS-485 (DB9 male)
Fieldbus: Profibus DP, 12Mbit (DB9 female)
Remote I/O: RS-485, up to 8 remote bases
SD flash card slot: Maximum support 32GB for firmware upgrade
Power supply voltage: +24V DC (typical value)
Power consumption: ≤ 8W (typical)
Operating temperature: 0°C ~ +60°C
Storage temperature: -40°C ~ +85°C
Installation method: 35mm DIN rail / MicroNet Plus rack slot (8 slots)
Protection level: IP20 (installed in the cabinet)
Certifications: CE, UL, CSA, TUV, ATEX (some versions)
Size: Approximately 90 × 120 × 55 mm (width × height × depth)
Weight: Approximately 0.5 ~ 0.8 kg
Operating system: MicroNet Plus real-time operating system
Programming software: WOODWARD TOOLbox / WOODWARD Configuration Suite
Recommended accessory modules
5466-1049: 24V DC power supply module, providing power for the entire rack
5466-1036: Micronet real-time network communication module
5466-1156: 16-point switch quantity I/O module (DI/DO)
5466-5026: 8-channel analog I/O module (AI/AO)
5437-672: Speed/phase input module
5453-203: Servo valve drive module
5441-693: 8-channel analog input module
5437-418: Relay output module
