I. Basic Model Positioning
Full part number: 8446-1068
Product name: Remote Monitoring Operation Panel for RP-3000 Generator Set
Main control: easYgen-3000XT series (3100XT / 3200XT / 3400XT / 3500XT) parallel controller for main units
Purpose: Independent cabinet-mounted human-machine interface for local remote start/stop, synchronization, load adjustment, and fault viewing of diesel/gas parallel power stations
Hardware and Interface Specifications
Power Supply
24VDC power supply for power station control (18-32VDC), low power consumption of the entire machine
Communication Bus
Special internal CANbus, only communicates with the same series easYgen generator controller, maximum wiring length of 100 meters
Display and Buttons
Two-line LCD backlit display, 24 characters per line, real-time display of frequency, voltage, active/reactive power, speed, fault code
function buttons: start/stop, synchronization closing, voltage regulation, speed regulation, fault reset, mode switching, page turning
Special red emergency shutdown button (hard contact output, independent safety circuit)
Installation Method
Standard embedded cabinet door opening installation, industrial IP54 front panel, suitable for distribution rooms, engine room environment
Environmental Parameters
Operating temperature: -20℃ ~ +60℃; no condensation and damp environment usage
Core Operating Functions
Local Unit Operation
Manual start/stop, emergency stop, no-load speed increase, load operation control
Synchronization Grid Connection Operation
Manual fine-tuning of frequency and voltage, monitoring phase difference, one-click control of generator circuit breaker GCB closing
Parallel Load Distribution
After multi-unit parallel connection, manual adjustment of active/reactive load distribution ratio
Fault Alarm and Recording
Real-time display of overspeed, overcurrent, underfrequency, overvoltage, water temperature oil pressure, differential protection, etc.; store historical fault records, support one-click reset of alarms
Mode Switching
Local manual / remote DCS automatic / island independent operation of three control modes switching
Parameter Simple Viewing
Can browse key running parameters of the unit, transformer ratio, synchronization window parameters without the need for a computer
IV. System Complementary Architecture
Single unit solution: 1 easYgen-3X00XT main controller + 1 8446-1068 remote panel
Multi-unit Parallel Connection: Multiple easYgen controllers connected via CAN bus, each unit can be separately equipped with an RP-3000 panel
Communication Restrictions: Cannot directly connect to old speed regulators of 505/2301A/8402 series, only compatible with the new generation easYgen 3000XT generator controller
Series Panel Differentiation (Cannot Be Directly Interchanged)
8446-1068: Standard RP-3000 basic model, compatible with all easYgen-3000XT
8446-1048: Simplified RP-3000, different button layout and opening dimensions
8446-107X: Touchscreen RP-3000XT, with large touch screen, hardware interfaces are incompatible
Typical Application Scenarios
Multi-unit diesel generator parallel system in industrial plants
Data center, hospital backup emergency power station
Auxiliary engine power parallel control cabinet for ships
Gas distributed energy microgrid
Mobile power station for mining in the wild for centralized monitoring
