Woodward LS5-XT / LS-5 Circuit Breaker Synchronization Controller

Product Description

Woodward LS5-XT / LS-5 series is a circuit breaker synchronizer controller (paralleling relay), Version 2. It integrates synchro-check, mains decoupling, protection and power management functions, commonly paired with Woodward easYgen-3400XT / 3500XT genset controllers. It communicates with genset controllers via CAN bus, measures voltage and current signals to perform synchronization, load transfer, mains failure detection and trip protection. It is software configurable for 1-breaker or 2-breaker modes. LS5-XT is the variant optimized for XT-series easYgen. Two hardware styles are available: rear-mounted unit without display and front-panel mount unit with LCD HMI. Widely applied in switchgear and generator paralleling systems in power plants.

Specifications

• Part No.: LS-5 (LS5-XT) V2
• Brand: Woodward
• Type: Circuit Breaker Synchronizer / Paralleling Controller
• Power Supply: 8–40 VDC, nominal 12/24VDC
• Power Consumption: Max ~5W for LS-511; Max ~6W for LS-521
• Operating Temperature: -20℃ ~ +70℃
• Storage Temperature: -30℃ ~ +80℃
• Humidity: 95% non-condensing
• Measuring Voltage: 120Vac / 480Vac (software selectable)
• Accuracy: Class 1
• Frequency: 50/60Hz
• Communication: CAN bus, RS232, service port
• Core Functions: Synchro-check, paralleling control, mains loss detection, mains decoupling protection, programmable LogicsManager
• Mounting: LS-511 rear mount aluminum housing; LS-521 front panel mount with backlit multilingual graphic LCD
• Configuration Software: Woodward ToolKit

Applications

1. Generator-to-utility paralleling, synchro-check and breaker control
2. Bus tie breaker and generator group breaker power management
3. Mains fault detection and automatic decoupling protection against islanding
4. Multi-generator parallel power stations (diesel / gas gensets)
5. Backup power ATS control for industrial plants, data centers and hospitals
6. Complete power management system integrated with Woodward easYgen-3400XT / 3500XT

LS-5 / LS5-XT Series Part Numbers

• LS-511 V2: Aluminum rear mount, no display, 1-breaker control
• LS-521 V2: Plastic front panel mount, graphic LCD, 1-breaker control
• LS-512 V2: Aluminum rear mount, 2-breaker control (software switchable to 1-breaker)
• LS-522 V2: Front panel mount with LCD, 2-breaker control
• LS-6XT: Higher performance multi-breaker synchronizer (upgrade model of same platform)
