ProSoft 6104-WA-PDPM Wireless PROFIBUS DP Master Gateway

ProSoft 6104-WA-PDPM Wireless PROFIBUS DP Master Gateway Detailed Explanation
This is a ProSoft (ProLinx) industrial-grade wireless DP master gateway. The corresponding slave model in the series is 6105-WA-PDPS. It mainly uses wireless links to replace the traditional wired RS485, enabling the establishment of a flexible PROFIBUS DP industrial network.

I. Model Meaning
6104: Product series number; WA = Wireless; PDPM = Profibus DP Master (DP master station), responsible for controlling the slave devices on the entire DP bus. Table
Parameters Specification Details
Power Supply Specifications Rated 24VDC, allowable range 18~36VDC, maximum current at full load 500mA
DP Wired Interface RS485 standard, baud rate 9.6kbps~12Mbps, up to 122 DP slave stations can be connected
Wireless Frequency Band 2.4GHz industrial frequency band, equipped with ProSoft self-developed PWP private wireless protocol, compatible with 802.11b/g/n
Operating Temperature Range Operation -20℃~50℃; Storage -40℃~85℃
Humidity Conditions 5%~95% without condensation, cabinet IP20 protection
Overall Machine Size Standard version: 132×52.5×114.8mm, DIN rail installation

Core Functional Features
Wired DP Wireless Expansion
Local wired connection to PLC/Controller DP port, paired with remote 6105-WA-PDPS slave station gateway via wireless and remote gateway, then connecting on-site frequency converters, remote IO, and instruments, eliminating the need for cross-region wiring construction.
Flexible Networking Mode
Supports point-to-point and one-point-to-multipoint topologies, suitable for multi-point access scenarios of mobile devices; built-in unified shared database, real-time two-way synchronization of data between master and slave stations.
Native DP Master Station Capability
Can independently manage all DP slave station nodes, supports DP V1.0 standard, comes with link diagnosis and disconnection alarm, suitable for traditional DP legacy equipment upgrade.
Industrial Anti-interference Optimization
Exclusive industrial wireless protocol optimizes frequency hopping mechanism, avoids workshop Wi-Fi and motor electromagnetic interference, ensuring continuous communication of mobile devices without dropping.

Typical Application Scenarios
Mobile Device Communication: AGV carts, bridge cranes, rotating workstations, solving the problem of cable dragging and wear;
Complex Factory Area Renovation: Cross-workshop, obstacle-blocking areas, replacing excavation wiring projects;
Old DP System Upgrade: Low-cost expansion of remote measurement points for the original wired DP network;
Port, Logistics Sorting Line Mobile Site Link Control.
