Prosoft MVI56E-MNET Communication Module

Product Description

Prosoft MVI56E-MNET is an enhanced Modbus TCP/IP Client/Server communication module designed for Rockwell ControlLogix chassis. It mounts directly on the ControlLogix backplane, enabling seamless data exchange between ControlLogix PAC and a wide range of Modbus TCP/IP compatible devices, such as instruments, drives, and third-party PLCs. It supports both Modbus TCP Client and Server modes. The built-in Ethernet port allows local and remote configuration and online diagnostics. It is backward compatible with legacy MVI56-MNET and acts as a protocol gateway for heterogeneous industrial networksProSoft Te….

Specifications

• Platform: Rockwell ControlLogix single-slot chassis
• Protocol: Modbus TCP/IP (Client & Server)
• Ethernet: 10/100 Mbps auto-negotiation, auto crossover
• Backplane Current: 800mA @5VDC; 3mA @24VDC
• User Data Storage: Up to 5000 16-bit registers mapping
• Operating Temperature: 0°C ~ 60°C
• Storage Temperature: -40°C ~ 85°C
• Certifications: CSA, ATEX Zone2, IEC61010
• Features: Remote diagnostics, on-module Ethernet configuration, EtherNet/IP pass-through communication

Applications

1. Factory Automation: Connect ControlLogix PLC to Modbus TCP transmitters, flow meters, variable frequency drives
2. Power & Energy: Data collection between ControlLogix and intelligent power monitoring devices for power plants and substations
3. Water Treatment: Integrate field Modbus TCP equipment into Rockwell ControlLogix main control system
4. Oil & Gas / Process Industry: Protocol conversion between different control systems and SCADA data exchange
5. Building & Infrastructure: Upload data from smart field devices to ControlLogix platform

Related Series Models

• MVI56E-MNETXT: Extended temperature version, operating range -25℃ ~70℃
• MVI56E-MNETC: Modbus TCP Multi-Client module
• MVI56E-MNETCR: Multi-Client with reduced data block
• MVI56E-MNETR: Modbus TCP module with reduced data block
• MVI56E-MCM: Modbus RTU Master/Slave enhanced communication module
• MVI56E-SIE: Siemens Industrial Ethernet communication module
